Home > Products > Stainless Steel Chemical Equipment > High quality jacketed pot

High quality jacketed pot

FOB Price

USD $800 - $3,500 / Set

1 Set(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port Shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Mixer Type	Agitator
Product Type	Other, Many industry	Application	Other, Liquid and powder
Additional Capabilities	Drying	Place of Origin	Henan, China
Brand Name	Wanda	Model Number	WD500
Max. Loading Capacity	50-1000L	Voltage	380V
Power(W)	2.5KW	Dimension(LWH)	1600X900X1150
Certification	ISO9001	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

Food grade stainless steel material
High welding technical workmanship
CE and ISO9001 approved
Long lifetime
Can be customiz

High quality jacket kettle

Specifications:

1) Consist of pan-body,jacket,frame, agitator etc.
2) Can be heated by gas, steam, electricity
3) Food grade stainless steel 304
4) Capacities: 50-1000L

Jacketed kettle & jacketed boiler:

This equipment is widely used in pharmacy, food and chemical industry for cooking, boiling or

concentrating according to your requirements. It has the hot steam and electrical heating sources.

Besides it can be added with agitator and cover. All depends on clients. This equipment consist of

boiler body, stirring device, tilting system, worm wheel and worm rod. The boiler body can be rotated

within 180 degree. The material of the main part is food grade stainless steel 304 which is in accordance

with GMP standard. We can also make the jacketed kettle or jacketed boiler according to

your special demands.

Technology data:

	WD50		WD100	WD150		WD200		WD300		WD400		WD500
Capacity(L)	50		100	150		200		300		400		500
Jacketed pressure (Mpa)	< 0.2
Evaporation capacity (kg/h)	30	40		50	65		75		100		150
Heat area (m 2)	0.4	0.45		0.76	1.0		1.15		1.44		1.90
Energy consumption (kg/h)	33	44		55	72		90		110		165
N.W. (kg)	170	190		210	230		320		360		485
L×W×H (mm)	720X600X830	800X650X830		1350X650X1100	1400X700X1100		1450X800X1110		1500X850X1140		1600X900X1150
