double helix juicer/electric multifunction orange juice extractor
Parameter:
For pressing pineapple, tomato, apple and pear fruit and vegetable juice etc.
|
Model
|
LZ-0.5 |
LZ-1.5 |
LZ-2.5 |
|
Capacity |
500Kg/hr |
1500Kg/hr |
2500Kg/hr
|
Diameter of the screw (mm) |
Φ87.5 |
Φ175 |
Φ250
|
Power (kw) |
1.5 |
4 |
11 |
Spindle speed (rpm/min) |
400 |
400 |
400 |
Weight (kgs) |
100 |
240 |
480 |
Size (mm) |
1100×265×920 |
1560×450×1340 |
1980×680×1620 |
Usage and application:
is a spiral slag outlet direction along the bottom diameter increase gradually and the pitch decreases, when the material is the spiral propulsion, because the spiral cavity volume reduction, squeeze the material.raw materialsare added to the feed hopper, compression screw propulsion, Sheng juice is squeezedthrough the filter into the bottom ofannular gap is formed between the tapered portion, and waste through the spiral and regulating the discharge, mobile pressure head along the axial adjustable pore size. For the clockwise (equipment from the slag notch to the feed hopper end rotates the handwheel shaft bearing seat, adjustable head to the left, and vice versa, voids and narrow gap larger.) Change of pore size, adjust the slag resistance. You can change the slag rate, but if the gap is too small, in strong extrusion, part of slag particles and juice together through the filtering net is squeezed out, although the juice increased, but the juice quality relative decline, the void size should be required depending on the user specific process .
**************************************************************************************************************************************
Henan Wanda Chemical Equipment Co.,Ltd
Address:Entrance 1501, 15th Floor, Building B, Yaxin square, new district of east Zhengzhou, Henan, China.
TEL:+86 371 60101636
FAX: +86 371 60101635
Name:Cindy Fan
Wechat/QQ:405549483
Moble/Whatsapp:+86 15515583482
**************************************************************************************************************************************
1)How to choose suitable fruit pulp machine?Answer:You can tell me what kind of fruits will you handle with,and what about your capacity,then we can according to your information to quote you a suitable machine.
2)Can i adjust the voltage of the pulping machine?Answer:Yes,we accept your modify about the voltage comply with different country’s requests.
3)If we want to reduce the time of beating,what we need to do?Answer:You can crush fruits and vegetables,or you can precook the fruits and vegetables,then put them into the pulping machine. It will reduce the pulping time and make the final size more uniform.
4)Can we adjust the size of final fruits and vegetable pulp?
Answer:There are different size of mesh screens,you can change the mesh screen to adjust the final pulp size.
5)What materials is the machine made up?
Answer:The whole machine is made up of 304 stainless steel,healthy and durable.
