Home > Manufacturing & Processing Machinery > Agricultural Machinery > Oil Presser > High Efficiency Oil-water Centrifuge/disc Type Oil Water Separator for Sale
High Efficiency Oil-water Centrifuge/disc Type Oil Water Separator for Sale
US$ 2,000 - 5,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Usage:
Olive Oil
Type:
Other, Disc-type centrifuge
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Weighing Packaging Machine /packaging MachineUS$ 1,500 - 5,000MOQ: 1 Set -
Best Price for Large Capacity Pneumatic ConveyorUS$ 2,200 - 8,000MOQ: 1 Set
-
Hot Seller 10% off Large Capacity Small Granular Materials Tubular Screw ConveyorUS$ 1,500 - 5,000MOQ: 1 Set
-
Vacumm Conveyor for Our Farm HouseUS$ 2,500 - 6,000MOQ: 1 Set
-
Long Distance Converying Vacuum Pneumatic ConveyorUS$ 3,500 - 7,000MOQ: 1 Set
Condition
New
Usage
Olive Oil
Type
Other, Disc-type centrifuge
Automatic Grade
Automatic
Production Capacity
5000-10000L/H
Place of Origin
Henan, China
Brand Name
WANDA
Model Number
DHZ550A
Voltage
220/380V
Power(W)
18.5KW
Dimension(L*W*H)
1850*1550*2050
Weight
2600, 300-520KG
Certification
CE ISO9001
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.Disc-type oil-water seperator2,strong ability of separation with simple structure
3.Low consumption
4.one year warranty
high capacity centrifuge disc-type separator
centrifugal machine /centrifuges suppliers
Test separator and installation:
A: check, before starting the spindle and the drum is connected preload, the upper end of a main shaft connecting joint and buffer rubber pad position is correct, whether the drum bottom shaft alignment marks the preload, the liquid inlet bearing fasteners, the connection is firm and reliable, appropriate tensioner tightness, power supply connection and zero connection protection and reliable, liquid disc pressing cap is pressed liquid disc, drum rotation direction is correct;
Two. The boot: starting power to observe any abnormal situation, the machine does not completely reach the normal speed, can not leave the operation power, nor feed;
Three. Feeding: when the machine is completely reaches the normal speed of charging, charging is slow, and the pressure should be less than 0.1Mpa, the discharge port discharge after adjustment to the normal feeding quantity;
Four. Stop: power off, wait for about 12 minutes, the machine energy completely stopped, in the machine is not completely stopped not any parts operating machine;
Five. Removing: determine the machine stops will be liquid disc pressure cap loose unload liquid dish, will drum out from the body, to work on the shelves with a special spanner will bottom shaft opened, three wing drum out, clear the drum solid phase, the operator should do the protective measures, must be completely remove the drum solid;
Six. Installation: drum after cleaning, the three wings of the mark in the drum, the bottom shaft installation. Should be installed in the threaded put some lubricant, check the seal is intact, the bottom shaft seat and the drum is marked, the bottom shaft and drum pre-tightening by pretightening force appropriate. If Mark misaligned, replaceable bottom shaft seal to adjust and correct, the drum into the machine, hydraulic disc connected into good spindle, pressing liquid dish.
A: check, before starting the spindle and the drum is connected preload, the upper end of a main shaft connecting joint and buffer rubber pad position is correct, whether the drum bottom shaft alignment marks the preload, the liquid inlet bearing fasteners, the connection is firm and reliable, appropriate tensioner tightness, power supply connection and zero connection protection and reliable, liquid disc pressing cap is pressed liquid disc, drum rotation direction is correct;
Two. The boot: starting power to observe any abnormal situation, the machine does not completely reach the normal speed, can not leave the operation power, nor feed;
Three. Feeding: when the machine is completely reaches the normal speed of charging, charging is slow, and the pressure should be less than 0.1Mpa, the discharge port discharge after adjustment to the normal feeding quantity;
Four. Stop: power off, wait for about 12 minutes, the machine energy completely stopped, in the machine is not completely stopped not any parts operating machine;
Five. Removing: determine the machine stops will be liquid disc pressure cap loose unload liquid dish, will drum out from the body, to work on the shelves with a special spanner will bottom shaft opened, three wing drum out, clear the drum solid phase, the operator should do the protective measures, must be completely remove the drum solid;
Six. Installation: drum after cleaning, the three wings of the mark in the drum, the bottom shaft installation. Should be installed in the threaded put some lubricant, check the seal is intact, the bottom shaft seat and the drum is marked, the bottom shaft and drum pre-tightening by pretightening force appropriate. If Mark misaligned, replaceable bottom shaft seal to adjust and correct, the drum into the machine, hydraulic disc connected into good spindle, pressing liquid dish.
Main technical parameter of centrifugal machine
Main technical parameter:
Model |
Handing capacity(l/h) |
Inlet pressure(mpa) |
Outlet pressure(mpa) |
Power(kw) |
Weight(kg) |
Dimension(mm) |
DHZ550E |
6000-15000 |
0.05 |
0.1-0.3 |
22 |
2600 |
1850*1550*2050 |
DHZ550A |
5000-10000 |
0.05 |
0.1-0.3 |
18.5 |
2600 |
1850*1550*2050 |
DHZ470 |
2500-7000 |
0.05 |
0.1-0.3 |
15 |
1700 |
1800*1200*1800 |
DHZ400 |
2000-4000 |
0.05 |
0.1-0.25 |
15 |
1500 |
1800*1200*1800 |
DHZ360 |
1200-2500 |
0.05 |
0.1-0.25 |
7.5 |
650 |
1500*1150*1500 |
DRZ550 |
1800-6000 |
0.05 |
0.1-0.3 |
22 |
2200 |
1620*1300*2200 |
DRZ400E |
4000-7500 |
0.05 |
0.1-0.35 |
7.5 |
850 |
1300*900*1500 |
DRZ400A |
2000-6000 |
0.05 |
0.1-0.35 |
7.5 |
800 |
1300*900*1450 |
DR(S)Z360 |
1200-2500 |
0.4-0.55 |
0.2-0.4 |
5.5 |
600 |
1250*1050*1500 |
Detailed Packing
If u are interested our products or u have any need for our products ,pls do not hesitate to contact me .I will try my best for u dear.
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2009
Factory Size
1,000-3,000 square meters
Total Employees
11 - 50 People
