SUS304 stainless steel horse manure dewatering machine
(Keywords: dewatering machine , manure dewatering machine , horse manure dewatering machine )
PRODUCT DESCRIPTION
| Power: 380V
Dimension: 1500*700*2000mm
Weight: 550kg
Diameter of filter screen: 200mm
Feed inlet diameter of submerged pump:76mm
Diameter of discharge port: 76mm
Outlet diameter of separated sewage: 108mm |
PARAMETERS OF HENAN WANDA SCREW EXTRUSION MANURE DEWATERING MACHINE
| Model | Motor power(KW) | Diameter of filter screen(cm) | Feed inlet diameter of submerged pump(mm) | Diameter of discharge port | Outlet diameter of separated sewage(mm) | Power(V) | Dimension(mm) | Weight(kg) |
| DLX200 | 4+3 | 20 | 76 | 76 | 108 | 380 | 2000*700*1500 | 550 |
| DLX280 | 5.5+3 | 28 | 76 | 76 | 108 | 380 | 2300*800*1500 | 680 |
| DLX300 | 7.5+3 | 30 | 76 | 76 | 108 | 380 | 2300*800*1500 | 680 |
HANDLING CAPACITY OF EACH RAW MATERIAL: LIQUID (solid content less than50%)
| Model | Raw material(m3/h) | ||||||
| Cow dung | Pig manure | Poultry dung | Duck manure | Biogas manure | Vinasse | Herb residue | |
| DLX200 | 8-10 | 8-12 | 8-12 | 8-10 | 5-10 | 10 | 5-7 |
| DLX280 | 15-20 | 15-20 | 15-20 | 15-25 | 15-20 | 15-20 | 15-20 |
| DLX300 | 18-25 | 18-20 | 20-25 | 20-25 | 15-20 | 16-20 | 15-20 |
SUS304 stainless steel horse manure dewatering machine
1. Application of horse manure dewatering machine
HENAN WANDA manure dewatering machine is mainly used to separate chicken dung, cow dung etc. into liquid and solid
fertilizer. Liquid fertilizer can be directly applied to agricultural plants and solid for needed areas. Also the fertilizer can
improve the earth or through fermentation made into organic fertilizer.
2. Operation principle of Biogas Slurry Solid Liquid Separator
Use sludge pump to pump original dung black water into the machine, through screw axis installed in the screen cloth, then press and separate the solid and the liquid flows out from the screen cloth.
3.Main feature of Biogas Slurry Solid Liquid Separator
Small sizes, low rotating speed, easy handle and installation, convenient repair, low cost, highly effective, fast investment recycle, no need any flocculant etc. The screw axis and screen cloth is Stainless steel.
PRODUCT SHOWROOM
EXCELLENT QUALITY FROM DETAILS
HENAN WANDA is devoted himself to R & D, manufacturing international brand dewatering machine of poultry excrement.
Main production equipments: cow dung dewatering machine, cow dung solid liquid separator, pig manure dewatering machine, pig manure solid liquid separator, poultry manure solid liquid separator, poultry manure dewatering machine.
HENAN WANDA not only supply equipments, but also supply solutions for customers! Kindly please see successful case we made for our customers:
DELIVERY SITE OF DOMESTIC AND INTERNATIONAL
CERTIFICATION
SERVICE TEAM ARE AVAILABLE FOR 24 HOURS
***********************************************************************************************************
Henan Wanda Chemical Equipment Co.,Ltd
Address:Entrance 1501, 15th Floor, Building B, Yaxin square, new district of east
Zhengzhou, Henan, China.
Name: Nancy Wang
Email: nancywanda(at)
Moble/Whatsapp:+86 18625859654
Wechat: 18625859654
FAX: +86 371 60101635
***********************************************************************************************************
