Help CenterFH20-90-2 Semi-automatic Can Body Welding Machine
Related Products
Specifications
Semi-automatic can body welding machineApply to the welding of various cans: food cans,and chemicals cans etc..
FH20-90-Ⅱ
Semi-automatic can body welding machine
Scope of application
Apply to the welding of various cans: food cans and chemicals cans etc..
Can body internal and external per painting machine and can body drier are optional to be added in production line.
According to customer's demands to accelerate the speed.
Main Technical Date
Linear rate of welding: 6-18m/min
Production capability: 20-40cans/min
Applicable can diameter: 220-290mm
Applicable can height 200-420mm
Applicable material : Tinplate steel-based
Applicable material thickness 0.22-0.42
Seam welding landing 0.8mm 1.0mm 1.2mm
Seam point distance 0.5-0.8mm
Applicable copper wire diameter Φ1.38mm Φ1.5mm
Cooling water : Temperature: 20°C Pressure: 0.4-0.5Mpa
Discharge: 7L/min
Power 380V±5% 50HZ
Total power 20KVA
Dimension 1200×1100×1800mm
Weight 1200KG
