Home > Packaging & Printing > Package & Conveyance > Packaging Cartons > 800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice

800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice

800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice thumbnail-1
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice thumbnail-2
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice thumbnail-3
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice thumbnail-4
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice thumbnail-5
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice thumbnail-6
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice photo-1
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice photo-2
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice photo-3
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice photo-4
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice photo-5
800~1200L Food Grade Paper IBC Container for Vegetable Oil, Water, Juice photo-6
US$ 50 - 100 MOQ: 10 Units
Key Specifications
Get Latest Price
Material:
Paper
Paper Type:
Kraft Paper
Industrial Use:
Food
Contact Supplier Request Quote Chat Now
Qingdao LET Flexitank Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Paper
Paper Type Kraft Paper
Industrial Use Food
Use Other, wine, oil
Feature Aseptic
Custom Order Accept
Place of Origin Shandong, China
Brand Name LET
Model Number Let-30

LET Paper IBC



Structure:  folding carton + double layers of liners + charging and

discharging port + waterproof treatment + pallet (waterproof

treatment and pallet are optional according to customer’s

requirement).

Specification:             800-1200L

Measurement:            1160*1160*1050mm

Thickness of cardboard:   30mm

Weight:                  55KG

Size of liner:               2150*2000mm



LET unique technology:

1, Compared with singe octagon carton, we combine inner octagon with outside square, it has better compression resistance and stability, maximum load-bearing to 8 tons.

2, Special anti-shake design ensures the safety when being used.

3, LET paper IBC can be fastened without pallet and unique loading design makes operation easier.

4, Special waterproof treatment makes IBC safer.

5, High-strength paper pallet or wooden pallet makes it convenient to transport.



I.Technical data

Structure of Paper IBC

1,folding carton

2,double layers of liners

3,charging inlet and discharging outlet

4,waterproof plastic bag

5,pallet (pallet is optional according to customer’s requirement).

Specification

800-1200L

Measurement

1140*1140*1100mm

Thickness of liner

125Mic(0.125mm)

Thickness of cardboard

30mm

Weight

55KG

Size of liner

2150*2000mm

Liner Tensile strength(N)

126.54

Liner Elongation at break(%)

451.46



II.LET unique technology:

1, Compared with singe octagon carton, we combine inner octagon with outside square, it has better compression resistance and stability, maximum load-bearing to 8 tons.

2, Special anti-shake design ensures the safety when being used.

3, LET paper IBC can be fastened without pallet and unique loading design makes operation easier.

4, Special waterproof treatment makes IBC safer.

5, High-strength paper pallet or wooden pallet makes it convenient to transport.



  800~1200L food grade paper IBC container for vegetable oil, water, juice800~1200L food grade paper IBC container for vegetable oil, water, juice800~1200L food grade paper IBC container for vegetable oil, water, juice800~1200L food grade paper IBC container for vegetable oil, water, juice
