Specifications
Furnace Refractory Ramming massGood thermal shock & corrosion resistance
Excellent mechanical strength
Stable life cycle
Metallurgical industry monolithic refractory ramming mass for induction furnace
Benefits:
1) Good performance to thermal shock, corrosion, erosion and abrasion resistance.
2) High refractoriness and excellent mechanical strength.
3) Both intermittently and continuously working mode are acceptable, reducing lining cracks.
4) Longer and stable life cycle to reach high efficiency.
5) Suit for all kinds of metal types, reduce residue and porosity of the products.
6) Labor and cost saving by convenient installation and maintenance.
| Items | HS-1 Series | HC-2 Series | HM-5 Series | HA-8 Series |
| Chemical property | acidity | slight alkaline | alkaline | neutral |
| Main contents | quartz | spinel | magnesia | corundum |
| Density (g/cm3) | >2.38 | >2.81 | >2.89 | >2.95 |
| Linear changing rate (%) | 0.14 | 0.09 | -0.01 | 0.02 |
| Grain size(mm) | 0-8 | 0-8 | 0-8 | 0-8 |
| Refractoriness(°C) | 1700 | 2100 | 2100 | 2300 |
| Compressive strength(MPa) | 39 | 56 | 59 | 62 |
| 1500°C×2h> | ||||
| Thermal shock resistance | good | very good | good | excellent |
| Suggested furnace Size | ≤ 10 metric tons | ≤ 5 metric tons | ≤ 3 metric tons | ≤40metric tons |
| Installation mode | dry vibration | dry vibration | Wet ramming | dry vibration |
| Suggested working mode | Intermittently or continuously | Intermittently or continuously | continuously | Intermittently or continuously |
| Application | acid material smelting; such as cast iron, copper-aluminum alloy, low alloy steel, etc. | alkaline material smelting; such as stainless steel, high manganese steel, high alloy steel, etc. especially the pocking and residue metal smelting. | alkaline material smelting, such as carbon steel, high manganese steel, etc, especially for manganese alloy series smelting. | suitable for all kinds metal types. |
| Suggested storage life | 6 months in dry condition | |||
Our packing:
1) Net weight 25kg per units(plastic woven bag); 1 metric ton in P.P bag(waterproofing) with sling.
2) Net weight 25kg per units(plastic woven bag); 1 metric ton on pallet with plastic film.
3) As customer's request.
Delivery: 10-30 days according to the quantity
1.Your inquiry related to our products or prices will be replied in 24hours.
2.Manufacturer with large capacity,ensure the fast production cycle after confirmed the order.
3. Our professional technicians will answer all your enquires in fluent English
4. To meet the refractory solutions, we can arrange our technicians to customers’ plant if needed.
5. Protection of sales area and private information for all of our customers.
Xiangtan Hexinsheng New Material Co., Ltd. specializes in manufacturing high quality monolithic refractory with the right of import & export. Our company has successfully passed ISO9001:2008 quality system certification in May 2012.
With a wide range, good quality, and reasonable prices, our products are extensively used in foundry, steel alloy melting, cement kiln other industries. “Creditability and Sincerity” is the principle of our business; our monolithic refractory products are widely recognized and trusted by users and can meet energy-saving and cost reducing.
