Insulation Fire Brick Fire Insulation

Insulation Fire Brick Fire Insulation thumbnail-1
Insulation Fire Brick Fire Insulation photo-1
US$ 0.3 - 0.9 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Shape:
Brick
Material:
Alumina Block
Contact Supplier Request Quote Chat Now
Hebei Color Season Metals And Minerals Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Shape Brick
Material Alumina Block
Al2O3 Content (%) 30%~40%
Brand Name VMC

Specifications

Fire clay bricks with good high temperature resistance capability, widely used for boilers and different kilns and furnaces.

Insulation Fire Brick Fire Insulation

Insulation Fire Brick Fire Insulation

Insulation Fire Brick Fire Insulation

Insulation Fire Brick Fire Insulation

Insulation Fire Brick Fire Insulation



Fireclay bricks is Al2O3 content of 30% to 40% aluminum silicate clay material products,  with 50% clay and 50% soft hard clay clinker, As the size requirements for certain ingredients,



after forming, drying, firing at a high temperature of 1300 ~ 1400 ℃. temperature of  1300 ~ 1400 ℃. common brick, special-shaped brick. They are widely applied in coke oven,



blast furnance, air stove, molten steel ladel, gating system, boiler, cement kiln, glass kiln, kinds of
kiln lining and thermal equipment.




Fire clay bricks

Dimension

 230*114*65(mm)

Bulk Density

  2.05,2.1-2.15, 2.3-2.4, 2.4, 2.5

Packaging Details

 Pallet covering by PE membrane

Applications

Metallurgy, Chemical industry, Heat treatment furnace.





Insulation Fire Brick Fire Insulation



Fire clay brick technical data





item

 SK-32

SK-34

SK-36

SK-37

SK-38

AI2O3(%)

38

42

50

65

70

Fe2O3 (%)

3

2.5

2.5

2.4

2

Refractoriness (SK)

32

34

36

37

38

Refractoriness under load, 0.2MPa, Ta, ((°C)

1300

1350

1450

1550

1580

Porosity (%)

26

25

 24

23

23

Bulk density (g/cm³)

2.05

2.1-2.15

2.3-2.4

2.4

2.5

Cold crushing strength (MPa)

25

25

45

45

51

Thermal expansion at 1000°C (%)

0.6

0.6

0.3

0.5-0.7

0.6







Insulation Fire Brick Fire Insulation





 Fire Clay Brick Features



1. Low bulk density, low thermal conductivity, good thermal insulation performance.



2. Good chemical stability,stable high temperature performance



3. Good integrity with furnace lining, long service life, easy operation.



4. Can be used in various kilns because of its cheapness and general tray package.



5. Easy to cut,shaped freely.
