Home > Products > Plastic Random Packing > Good Quality Conjugate Ring K023
Good Quality Conjugate Ring K023
- 3500 Cubic Meter / Cubic Meters per Month
- SHENZHEN SHANGHAI
- T/T
Product Details
| Place of Origin: | Jiangxi, China | Brand Name: | KANGYU | Model Number: | Plastic Conjugate Ring |
| Plastic Modling Type: | Blow Molding |
Product Description
Conjugate Ring
Introduction
Plastic Conjugate Ring packing is made from heat resistant and chemical corrosion resistant plastics, including PE, PP,RPP, PVC, CPVC, PVDF. It has features such as high free volume, low pressure drop, low mass-transfer unit height and so on, and the application temperature in media ranges from 60 Degree C to 150 Degree C. It is widely used in the packing towers in petroleum industry, chemical industry, alkali-Chloride industry, coal gas industry and environmental protection, etc.
Features
It is developed by South China University of Technology,It draws the benefits of ring and saddle packing, Because of conjugate curve rib structure and appropriate length,there are point contact and are not intussuesceptive between packings and tower and packings, It has better hydrodynamics and mass transfer performance.
Technical Data
ODXHGTXTHI mm | Surface Area m²/m³ | Free Volumn % | Bumber n/m³ | Bulk Density kg/m³ | Packing Factor m-1 |
16*8.9*1.0 | 370 | 85 | 299136 | 135.6 | 602.5 |
25*17.5*1.0 | 228 | 90 | 74000 | 65.2 | 312.8 |
38*19*1.2 | 132.5 | 91 | 18650 | 54.5 | 175.8 |
50*25*1.5 | 114.2 | 92.7 | 9200 | 49.2 | 143.1 |
76*38*2.6 | 90 | 92.9 | 3980 | 63.5 | 112.3 |
100*50*3.0 | 76 | 94.1 | 1800 | 45 | 101.1 |
Material: PP PE PVC CPVC PVDF etc
We promise to reply you in 24hours, OEM & ODM service for your unique idea with absolute convenience. We value our business credit, promise to keep your company information confidential.If any inquiry or problem.Please feel free to contact with me.
Grace Zhang
Whatsapp/TEL:008613767885030
QQ: 84781705
Skype: yakegrace
Wechat: xz9426
TM: cn1000900349
Q: What is your MOQ?
A: Our product MOQ is 1000kg&1m³
Q: What is the delievery time?
A: It takes aroud 10-15days for one 20" container.
Q: What is the shipping port?
A: Shanghai,Shenzhen,Qingdao.
Q: What is payment terms?
A: T/T,L/C, West Union.
Q: What information should I offer to you if I want to know the price?
A: Appication/usage,Size,Material,Quantity,Package term,Delievery time,Payment term,Destination.
Q: What is your warranty?
A: By National Standard GBT 10504-2008, Offer lifetime consultation on problems occurred.
Why choose products from KANGYU ?
1. Specialize in this field for more than 10 years.
2. More than 1000 workers, Strong ability of production.
3. Shorter delivery time.
4. Rich variety of products:molecular sieve,random and structured chemical packing in ceramic,plastic&metal honeycomb ceramics,inert ceramic balls,activated alumina,alumina grinding balls,expanded perlite,porous ceramic filter pipe and so on.
5. Competitive price,modern appearance.
6. Do any sticker you need(OEM,ODM).
7. Going green and environmental protection:No mercury, No radition, No UV.
8. Honesty is the most important
We Specialized in Manufacturing molecular sieve, random and structured chemical packing in ceramic, plastic & metal, honeycomb ceramics, inert ceramic balls, activated alumina, alumina grinding balls, etc.
We has an annual manufacturing capacity of 5000 ton molecular sieves, 20000 m3 of varieties types of chemical packings, 3000 m3 of honeycomb ceramics and 5000 m3 of inert ceramic balls, 2000 ton activated alumina etc.
Welcome to our factory and negotiate business. We trust we will be your best supplier in China.
