KANGYUPlastic Cascade Mini RRing.
Application: Random packing
Size:16mm 25mm 38mm 50mm 76mm
Material:PE PP PVC CPVC PVDF
KANGYU Plastic Cascade Mini Ring
Introduction:
Plastic cascade mini ring is made from heat resistant and chemical corrosion resistant plastics, including polyethylene (PE), polypropylene (PP), reinforced polypropylene (RPP), polyvinyl chloride (PVC), chloridized polyvinyl chloride (CPVC) and polyvinylidene fluoride (PVDF). It has features such as high free volume, low pressure drop, low mass-transfer unit height, high flooding point, uniform gas-liquid contact, small specific gravity, high mass transfer efficiency and so on, and the application temperature in media ranges from 60to 150. For these reasons it is widely used in the packing towers in petroleum industry, chemical industry, alkali-Chloride industry, coal gas industry and environmental protection, etc..
Technical data
Spec. |
D*H*T (mm) |
Numer per m³ |
Bulk density (kg/m³) |
Surface area (m²/m³) |
Free volume (%) |
F Factor m-1 |
Dg16 |
16*8.9*1.1 |
299136 |
135.6 |
370 |
85 |
602.6 |
Dg25 |
25*12.5*1.4 |
81500 |
97.8 |
228 |
90 |
312.8 |
Dg38 |
38*19*1 |
27200 |
57.5 |
132.5 |
91 |
175.8 |
Dg50 |
50*25*1.5 |
10740 |
54.8 |
114.2 |
92.7 |
143.1 |
Dg76 |
76*37*3 |
3420 |
68.4 |
90 |
92.9 |
112.3 |
Note: The above information is on the basis of material PP.
Product photo:
