Specifications
Metallic Rasching Ringhigh quality
Material: SS304 316 316L 410
Size: 16, 25, 38, 50,76,90mm
Certificate: ISO9001:2008
Metallic Rasching Ring
10 years experiences in producing for chemical random packing and structured packing, desiccant and ceramic ball
Introduction:
Metal rasching ring is made of materi als like carbon steel, stainless steel or Aluminum alloy, etc. The product has features such as thin wall, heat resistant, high free volume, high capacity, low resistance, high separation efficiency and so on. It is especially suitable for rectification towers under vacuum to treat thermosensitive, decomposable, polymerizable or cokable systems, so it is widely used in packing towers in petrochemical industry, chemical fertilizer industry and environmental protection, etc.
Technical data
Size |
Bulk density |
Number |
Surface area |
Free volume |
15×15×0.3 |
379 |
230000 |
350 |
95 |
25×25×0.4 |
318 |
51000 |
216 |
96 |
25×25×0.5 |
400 |
51000 |
220 |
95 |
35×35×0.8 |
430 |
19000 |
150 |
93 |
50×50×0.5 |
203 |
6500 |
106 |
97.4 |
50×50×0.7 |
285 |
6500 |
108 |
96.4 |
50×50×0.8 |
325 |
7000 |
109 |
95 |
76×76×0.8 |
212 |
1830 |
69 |
97.3 |
80×80×1.2 |
300 |
1600 |
65 |
96 |
90×90×1.0 |
236 |
1160 |
62 |
97 |
The above data is reference to material stainless steel (AISI304) in the material thickness shown.
Material available:
carbon steel, stainless steel including 304, 304L, 410,316, 316L.
