Bentonites' information:
Specifications
nonpoisonous,cohesiveness,expansibility,adsorption,commutation,catalyst,thixotropy,expanding supending,fire-resistant,plasticity
Bentonite
With good capacity of suspension and thixotropy, bentonite for directional through-passing is the same nature with Bentonite for Drilling Mud. It also has a lots of advantages, such as low filtrate volume, good capacity of mud-made, easydispose and etc. At the moment, many Non-dig companies have applied this kind of bentonite in many directional through-passing construction such as West-East natural gas transmission project, which has approved the bentonite for directional through-passing is the basic ideal material for all kinds of projects.
Physical index
itemsType |
first grade |
second grade |
third grade |
fourth grade |
Green Comp Strength , kpa ≥ |
100 |
70 |
50 |
30 |
Dry Comp. Strength, kpa ≥ |
2.5 |
2.0 |
1.5 |
0.5 |
MBI,g/100g |
32 |
28 |
25 |
22 |
Mesh(through B.S.S.200 sieve,%≥ |
85 |
85 |
85 |
85 |
Moisture % |
9~13 |
9~13 |
9~13 |
9~13 |
Chemical content
Ingredients |
% |
Sodium Bentonite |
Ca-bentonite |
SiO2 |
% |
69.32 |
67.23 |
Al2O3 |
% |
14.27 |
15.88 |
CaO |
% |
1.99 |
2.22 |
MgO |
% |
2.69 |
4.01 |
K2O |
% |
1.38 |
0.19 |
Na2O |
% |
1.85 |
0.13 |
Fe2O3 |
% |
1.84 |
2.62 |
FeO |
% |
0.63 |
0.03 |
MnO |
% |
0.10 |
0.00 |
TiO2 |
% |
0.13 |
0.13 |
P2O3 |
% |
0.04 |
0.06 |
LOI |
% |
5.67 |
8.09 |
usage
Bentonite has special properties, such as swelling power, cohesiveness ,catalysis, thixotropy, suspension property and cation exchange property and so on, so it is widely used in various industrial fields. according to the uses, bentonite is divided into bentonite for mechanical casting use, bentonite for metallurgy pellet, bentonite for drilling mud, bentonite for agricultural building materials, bentonite for civil engineering.
Bentonite for oil drilling
project |
Drilling Bentonite |
Untreated bentonite |
OCMA Bentonite |
Viscometer readings 600r/min≥ |
30 |
|
30 |
Yield Value / plastic viscosity≤ |
3 |
1.5 |
6 |
Filtration volume / cm 3≤ |
15.0 |
|
16.0 |
75μm sieve, mass fraction /% ≤ |
4.0 |
|
2.5 |
Dispersed plastic viscosity / (mPa · S)≥ |
|
10 |
|
After filtration the amount of scattered / cm 3 ≤ |
|
12.5 |
|
Water (105 ° C). Mass fraction /% ≤ |
|
|
13.0 |
Bentonite for foundry
project |
Drilling Bentonite |
Untreated bentonite |
OCMA Bentonite |
Viscometer readings 600r/min≥ |
30 |
|
30 |
Yield Value / plastic viscosity≤ |
3 |
1.5 |
6 |
Filtration volume / cm 3≤ |
15.0 |
|
16.0 |
75μm sieve, mass fraction /% ≤ |
4.0 |
|
2.5 |
Dispersed plastic viscosity / (mPa · S)≥ |
|
10 |
|
After filtration the amount of scattered / cm 3 ≤ |
|
12.5 |
|
Water (105 ° C). Mass fraction /% ≤ |
|
|
13.0 |
Bentonite for metallurgy
project |
Sodium Bentonite |
Ca-bentonite |
||||
Grade |
2 items |
Three Goods |
Grade |
2 items |
Three Goods |
|
Water absorption (2h) /% ≥ |
400 |
300 |
200 |
200 |
160 |
120 |
Blue absorption capacity/(g/100g) ≥ |
30 |
26 |
22 |
30 |
26 |
22 |
Swelling Index/(mL/2g) ≥ |
15 |
5 |
||||
Sieving ratio (75μm, dry sieving), mass fraction /%≥ |
98 |
95 |
95 |
98 |
95 |
95 |
Water (105 ° C). Mass fraction /% |
9-13 |
9-13 |
||||
Bentonite of JJP grade
Indicators |
Moisture absorption rate |
Moisture |
Size |
Dry grain compressive strength of |
Capacity |
Color |
Model |
>100 |
<10 |
1-4 |
>3 |
1.0±0.1 |
White, red, green |
