Insulation Aluminum Electrolysis Cell Calcium Silicate Board

Insulation Aluminum Electrolysis Cell Calcium Silicate Board photo-1
US$ 121 - 200 MOQ: 1 Cubic Meter
Key Specifications
Get Latest Price
Brand Name:
sunshine
Model Number:
1000*500*30mm/50mm
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Brand Name sunshine
Model Number 1000*500*30mm/50mm

Specifications

1.High strength
2.Non-toxic pollution-free
3.Coefficient of thermal conductivity small
4. heat insulation

Sunshine Calcium Silicate Board:

1. Introduction

Calcium Silicate refractory boards are specifically designed for molten metal applications. Components are machined for the movement, distribution, flow control and casting of non-ferrous metals and their alloys. The exceptional strength and durability of these boards insures that components are highly resistant to breakage during casting and subsequent cleaning. They have excellent resistance to metal flow.
2. Typical Applications:
· Floats Stoppers
· Dip tubes and spouts· Nozzles
· Distribution boxes, Flow gates
· Hot pipe supports
· Gaskets Rings

· Roller supports
· Heating tape supports



3. Technical Characteristics

· Excellent insulation power
· Excellent mechanical resistanace
· Excellent resistance to thermal shock
· Excellent acoustic and dielectric isolation

4.. Specification

The High Temperature (1100 degree) Refractory calcium silicate Board

Item

HT-170

HT-220

HT-240

Density(kg/m3)

170

220

240

Quality moisture content (%)

≤7.5

≤7.5

≤7.5

Compressive strength(Mpa)

≥0.40

≥0.50

≥0.60

Flexural strength(Mpa)

≥0.20

≥0.30

≥0.30

Termal conductivity(W/m.k)

≤0.048+0.00011T

≤0.050+0.00011T

≤0.056+0.00011T

Work temperature°C

1000°C

1050°C

1100°C

Linear shrinkage (%)

≤1.50(1000°C,3nrs)

≤1.50(1000°C,3nrs)

≤1.50(1000°C,3nrs)

Size

600*300*25-100mm,500*500*25-100mm ,1000*500*25-100

































Insulation aluminum electrolysis cell calcium silicate boardInsulation aluminum electrolysis cell calcium silicate boardInsulation aluminum electrolysis cell calcium silicate boardInsulation aluminum electrolysis cell calcium silicate board
