Automatic mosquito-repellent incense making machine
1.Large mixing: mix all raw materials together, and get ready to next grout mixer.
2. Grout mixer: put starches into the machine, cook the starches by boiling water or steam.
Using water or steam Jie Ke, mixing pulp evenly.
Specifications:
Motor Power: 1.5KW
Capacity: up to 50 kg each
Overall: φ900mmx1700mm
3. Small mixer: put the raw materials which are mixed by the first step and the starches that it is cooked together , and then they are called the wet green
This machine has a design and generous, simple operation, easy maintenance, automatic reversing feed and so on. Stir in hand to install a simple, durable wear-resistant, weldable change, reduce production costs.
Specifications:
WD-100
Motor Power: 5.5KW
Capacity: up to 100 kg per mixing
Homogenization time: 12 minutes
Dimensions: 2300mmx1100mmx1300mm
WD-200
Motor power: 11KW
Capacity: up to 200 kg per mixing
Homogenization time: 12 minutes
Dimensions: 2800mmx1300mmx1300mm
4.The forming machine: put the ready mixed wet greens into the forming machine. After going through the second pressure, it will form the mosquito wet-green.
Production efficiency:
22680 / hour (in 18-mode as an example)
Motor total power: 27.65KW
Operator: 4 people
Sieve plate size: 900mmx450mmx40mm
5.The drying room: push the mosquito wet-green into the drying room, dewater, drying for a while , and then it is the mosquito dried-green. ( this is a local building)
6.Automatic mosquito-repellent molding machine:
the machine will collect the mosquito-repellent incense automatically. And will get ready to next step: spraying.
Motor power: 3.45KW
Received quantity: 4-7 trucks per hour
Dimensions: 3500mmx2400mmx1400mm
7. Automatic piece-distribution machine: collect the mosquito-repellent incense
together , and send them into the next step.
8.Stainless steel chemical spray: when the mosquitos come in this machine, the machine will spray the chemical drugs onto the mosquito-repellent incense
, in order to kill the mosquitos.
Motor Power: 1.2KW
Spraying rate: single 150 / min dual-channel 300 / min
Dosage error: ± 5%
Overall: 2300mmx650mmx1200mm
9. Assemble: put the mosquito-repellent incense into the package, then into the carton, and collect them into the arehouse.
All the machines above and their functions are mature in China at present. And the production scale is according to the production lines, one line can produce 135000~165000pcs 8 hours/ day under normal production conditions of domestic.
If you are interested in our products, please contact with me!
