Fiber Cut-off Machine
Description:
The machine can be used to cut all kinds of fabric rags. Such as glass fabric, aramid fabric,aynthetic fabric and so on. The Cutting machine has one fixed blade and two movable blades. With the help of high rotation of movable blades roller, the raw material will be cut into small pieces when they pass the fixed blade.
It is made and designed on the base of better character and advanced experience of the similar product domestic and abroad. In addition, it can meet the requirement of best quality, high output, low cost and also has a feature of reasonable structure, easy operation and safe production and so on.
Specifications:
Model |
500B |
800C |
800D |
1600B |
Motor |
3.0+1.1kw |
4.0+1.5kw |
5.5+1.5kw |
11+3.0+0.75+0.75+1.5 kw |
Size |
3200*1000*1100mm |
3200*1000*1200mm |
6000*1000*1200mm |
7000x1800x1950mm |
Capacity |
300kg/h |
500-800kg/h |
500-800kg/h |
1000-2000kg/h |
Cutting Size |
5-300mm can choose one fixed size |
5-150mm can choose three sizes |
5-150mm can choose three sizes |
5-150mm can choose three sizes |
Moving Knife Material |
Quality carbon structural steel 2-4knifes |
alloy tool steel 2-4 knifes |
alloy tool steel 2-6 knifes |
alloy tool steel 2-6 knifes |
Fixed Knife Material |
Single blade alloy steel |
Double alloy tool steel |
Hard Alloy Steel |
Double row two edges special alloy tool steel |
Cutting Thickness |
20mm |
30-50mm |
30-50mm |
30-100mm |
Pictures:
If you are interested in our products, please contact with me !
