V shape Dry Powder Mixer
Model name: JHX series double movement powder mixer
Video Center on Youtube: /watch?v=63XJ723AfMc
You can also find us on Facebook by name-Aicy Chian
Application: Pharmaceutical industrial, Food industrial, Chemical industrial, Metallurgy Industrial, Refractory Industrial, Medicine Industrial, Tea industrial, Nutrition Industrial, etc
Advantages of our JHX series powder mixer machine :
1. Double revolving shaft mixer with two mixing systems, 8 eight spiral blades inside the barrel
2.Saving time 50% , electricity70% and 30%space.
3.Easier feeding material and getting of material.
4.Patent Ownership, independent R&D.
Double movement principle:
JINHE ® double movement powder mixer is a new technical revolution in mixing machine field. With the double movement system, it can mix the stuff successfully by container movement, while the superposed moving inside blades also convective mixing the mixture.
The 1st movement system drive the container to rotating, which can mix the inside stuff by doing irregular movement.
The 2nd movement system drive the inside full-size blades pressing, cutting and mixing mixtures with different speed and in different direction
Model |
Barrel Capacity (L) |
Max Barrel Capacity (L) |
Max Barrel Weight Capacity(kg) |
Barrel Revolution Speed |
Blade Revolution Speed |
Motor Power |
Size (mm) |
Weight |
JHX50 |
50 |
35 |
60 |
25 |
50 |
1.1 |
1620×580×1060 |
430 |
JHX100 |
100 |
75 |
110 |
23 |
46 |
1.1 |
1780×670×1240 |
500 |
JHX200 |
200 |
140 |
240 |
21 |
42 |
2.2 |
2060×800×1400 |
660 |
JHX400 |
400 |
280 |
500 |
17 |
34 |
3.0 |
2500×950×1610 |
910 |
JHX600 |
600 |
420 |
700 |
17 |
34 |
4.0 |
2650×1050×1800 |
1200 |
JHX600Z |
600 |
420 |
1000 |
14 |
28 |
5.5 |
2000×1280×1800 |
1400 |
JHX800 |
800 |
560 |
800 |
14 |
18 |
5.5 |
2000 |
|
JHX1000 |
1000 |
700 |
1000 |
11 |
22 |
11 |
2530×1650×2070 |
2300 |
....
