CE ISO Fog Cannon
Main features
1. Strong capability, high & far throw range, wide coverage area, achieve precise volume spraying, high efficiency and spray speed.
2. Micro fog droplet, form a wet mist touching the floating dust, high speed knock down the dust.
3. Flexible power: three-phase 380V and diesel generator power supply optional
4. Flexible installation, fixed on the concrete platform or diesel generator-powered vehicles optional.
5. Flexible, safe & reliable to use. Remove control & manual control operation. Easily adjust the spray angle of horizontal rotation.
6. Compare to tank car, water consumption save 70% ~80%, wide coverage area.
Application
The area of environmental protection industry, mining, coal yard, docks, steelworks and other dust relatively large construction site.
Technical Parameters
| Model | FS200 |
| Matched power | 250kw |
| Flow rate | 80-320L/min |
| Horizontal range | 175-200m |
| Vertial range | 75-85m |
| Fan power | 110kw |
| Working pressure | 1.0-2.0MPa |
| rotation angle | 350 degree |
| Items |
Dimension (m) |
Matched power (kw) |
Rated flow (L/min) |
Horizontal range (m) |
Vertial range (m) |
Fan power (kw) |
Working pressure (MPa) |
Pitch angle (degree) |
Rotation angle (degree) |
| FS60 | 1.25*1.00*2.00 | 20 | 20-80 | 50-60 | 30-38 | 7.5 | 1.0-2.0 | -10-40 | 350 |
| FS80 | 1.55*1.20*2.20 | 24 | 20-120 | 60-70 | 36-45 | 11 | 1.0-2.0 | -10-40 | 350 |
| FS100 | 1.60*1.40*2.50 | 50-60 | 40-160 | 80-100 | 45-55 | 30 | 1.0-2.0 | -10-40 | 350 |
| FS150 | 2.00*1.75*3.00 | 110 | 60-240 | 130-150 | 65-75 | 55 | 1.0-2.0 | -10-40 | 350 |
| FS200 | 2.00*1.72*3.10 | 250 | 80-320 | 175-200 | 75-85 | 110 | 1.0-2.0 | -10-40 | 350 |
Certification
Photos of industry sprayer
Working view
We supply many kinds of sprayer
