Specifications
farming harrow disc plough disc bladeDiameter: 14-36 inch
Thickness: 3-12 mm
Edge: Round and Notched
disc blade plow plane plough discs for sale used
Disc Blades are extensively used for agricultural equipment, such as disc harrow & disc plough. It offered in 65Mn spring Steel (high-carbon steel) material in smooth disk blade and notched disk blade. Offered in different diameters from 14” to 36” and thicknesses from 3mm to 12mm. Disc Blades are carefully heat treated to engage with the rocks, boulders and other obstructions. These feature superior corrosion resistance with less maintenance requirements. The durable finish also results in providing longer service life of disc blades as well as more wear resistance while being used on soil.
Technique parameter:
| Dimension of disc blade | |||||
| Diameter (D) | Concavity (H) | Thickness of disc | R | Sharpening | |
| MM | INCH | MM | MM | MM |
|
| 255 | 10 | 12 | 3 | 460 510 540 570 600 610 630 650 685 750 900 |
External / Internal |
| 305 | 12 | 19 | 3 | ||
| 330 | 13 | 25 | 3 | ||
| 355 | 14 | 38 | 3 | ||
| 410 | 15 | 38~50 | 3 | ||
| 430 | 17 | 57 | 3/4 | ||
| 460 | 18 | 38~60 | 3/4 | ||
| 480 | 19 | 57 | 3/4 | ||
| 510 | 20 | 44~63 | 3;4;5 | ||
| 535 | 21 | 63 | 3;4;5 | ||
| 560 | 22 | 60~85 | 4;5;6 | ||
| 585 | 23 | 75~90 | 4;5;6 | ||
| 610 | 24 | 75~95 | 4;5;6 | ||
| 660 | 26 | 86~115 | 5;6;7;8 | ||
| 710 | 28 | 100~130 | 5;6;7;8 | ||
| 760 | 30 | 120~135 | 6;7;8;10;12 | ||
Our company Shandong Tiansheng Machinery Co., Ltd , a private enterprise specializing in developing, selling and producing the agricultural machinery, which is China's outstanding agricultural expert, we have self-supported import and export right.The quality of our products is reliable and the performance is well.The main products of Shandong Tiansheng Machinery Co., Ltd. include: Qingquan brand disc harrow, disc plow, mouldboard plow, rotary tiller, potato planting (harvest) machine, cultivator, subsoiler, seeder, leveler, ridger, trencher, stubble cleaner, earth auger, fertilizer distributor, farm trailer, and the other farm machinery.
The main market is Africa,Latin-America, Europe , South-east Asia and so on.
BV certification
iso certified companies manufacturer
1, Nude packing for disc blade and trailer;
2, Iron box packaging for small quantity or less than container load.
3, Full container load
Terms of Payment:
--TT,30% as the first payment and the balance before shipment.
--Irrevocable LC at sight
--DP at sight
Contacts:
Sofia Han
Mobile:008613645340809
Skype:sdtsexport01
Looking forward to your kind inquiry!
