Home > Products > Disc Harrow > tractor mounted 3point disc harrow for agriculture cultivator

Share|

tractor mounted 3point disc harrow for agriculture cultivator

Name: tractor mounted 3point disc harrow for agriculture cultivator
Brand: Qingquan
Price: USD $840 - 870 / Set

FOB Price

USD $840 - $870 / Set

4 Sets(Min.Order)

Supply Ability 10000 Set / Sets per Month
Port Qingdao
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Type:	Farm Cultivator	Power Type:	Other, tractor
Certification:	BV ISO9001	Warranty:	1 year	Use:	cultivation
Place of Origin:	Shandong, China	Brand Name:	Qingquan	Model Number:	1BQX
Weight:	180 kg	Dimension(LWH):	1.81.50.8	After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

iron-net box or as your requirement

Product Description

1BQX Series Light Duty Offset Disc Harrow is designed specially for small areas that are difficult to harrow and with steep slopes. The disc harrow is used for breaking up the ground, shattering soil lumps and mixing crop residues into soil as green manures. Three point mounted with tractor and harrow’s compact structure make the harrow perform excellently in steep land with high speed.

Technique parameter:

• 28×28 square harrow shaft used, 200mm spacing between discs
• High Carbon disc blade hardness: 38-44 HRC, assuring the toughness and wear ability of disc blade.
• Compact harrow structure, convenient for assembly and adjustment
• High harrowing speed and efficiency when three point mounted with tractor rear
• Especially performing well in rugged land with more steep slopes
• Disc harrow adopting using bearing combinations with a grease filling hole on it, keeping sand or soil from going into bearing to cause break down and maintaining conveniently

model	unit	1BQX-1.1	1BQX-1.3	1BQX-1.5	1BQX-1.7	1BQX-1.9	1BQX-2.3
Working width	m	1.1	1.3	1.5	1.7	1.9	2.3
Working depth	mm	120
Q’ty of disc		12	14	16	18	20	24
Disc diameter	mm	460	460	460	460	460	460
Total weight	kg	200	220	240	260	310	360
matched power	hp	12	15	25	30~35	35~45	50
Linkage		Standard three-point mounted

Company Information

---Product:Disc harrow,discplough,mouldboardplough,rotarytiller,trailer,mower,spreader,seeder ,thresher,Potato planter and harvester,rear blade,cultivator,disc blade,all kinds of farm machiner parts.

---we are the only one draft of China disc harrow and mouldboard plough standard as manufacturer unit

---we are quality supplier of domestical tractor manufactuer,like YTO,Foton Lovol

---we are the recommended unit of the farm implement project at home and abroad , we also sent our engineers to those countries to help the assembling and using for one year around which enjoy good remarks

---158 employees and 66 engineers and technicians

--- the main market is Africa,Latin-America, Europe , South-east Asia and so on.

Our company Shandong Tiansheng Machinery Co., Ltd , a private enterprise specializing in developing, selling and producing the agricultural machinery, which is China's outstanding agricultural expert, we have self-supported import and export right. The quality of our products is reliable and the performance is well. The main products of Shandong Tiansheng Machinery Co., Ltd. include: Qingquan brand disc harrow, disc plow, mouldboard plow, rotary tiller, potato planting (harvest) machine, cultivator, subsoiler, seeder, leveler, ridger, trencher, stubble cleaner, earth auger, fertilizer distributor, farm trailer, and the other farm machinery.

The main market is Africa, Latin-America, Europe, South-east Asia and so on.

FAQ

1. Are you a trade company or a manufacturer?

We are a manufacturer who have factory of ourselves, and we have our own Foreign Trade Department for exporting since 2005.

2. Where are you located in and which port is the nearest?

We are located in Yucheng City, Shandong Province of China, about 50 minutes driving distance to Jinan City. The nearest port is Qingdao, sometimes we also export from Tianjin Port and Shanghai Port.

3. What’s your main products?

We mainly produce tractor matched implements and their spare parts. Our agricultural implements can match with wheel tractors of JOHN DEERE, NEW HOLLAND, MASSEY FERGUSON, SONALIKA, KUBOTA etc., and China’s brands like YTO, FOTON LOVOL, BOMR etc..

4. What’s your delivery time?

Normally 15-20 days if quantity less than one container, about 30 days if one container quantity.

5. Do you have the ability and accept OEM or ODM?

Yes, of course. We have experienced processing craft to undertake OEM, and we also have technical designing experts to undertake ODM.

6. How can I trust your company and products? Do you have some certificates?

We’ve been exporting agricultural implements since 2005, having many distributor and user customers in 66 different countries, who praise highly of our company’s service and product quality.

And we annually undertake China’s Aiding Projects of Agricultural Machinery directed by the Ministry of Commerce of the People's Republic of China, we winned reputation by our product quality.

We have ISO9001: 2008 Certificate, BV(Bureau Veritas) Certificate.

After-Sales Service

Packaging & Shipping

1, Nude packing for disc blade and trailer;

2, Iron box packaging for small quantity or less than container load.

3, Full container load

Payment Terms

--TT,30% as the first payment and the balance before shipment.

--Irrevocable LC at sight

--DP at sight

Sofia Han

Mobile:0086-13645340809

Skype:sdtsexport01

Company Profile

Shandong Tiansheng Machinery Co., Ltd.

Shandong Tiansheng Agricultural Machinery Co., Ltd , a private enterprise specializing in developing, selling and producing the agricultural machinery, is the drafter of the industry standard of the disc harrow and share plough in China,which is China's outstanding agricultural expert, we have self-supported import and export right, In July 2006, Our company has passed ISO9001:2000 quality management system certification.
Our company is located in High and New Technology Development Zone Yucheng City, Shandong Province, Covers an area of 32000 square meters including more than 15000 square meters standard workshops.There are 120 sets of various machinery equipments,158 employees and 66 engineers and technicians.
We mainly produce with the brand of qingquan:disc harrow,disc plough,share plow, rotary tiller,potato planter,potato harvester,cultivator,subsoiler,seeder,box blade,ridger,ditcher,stubble cleaner,hole digger, fertilizer spreader, farming trailers and so on. We can yearly produce 20,000 sets of complete machines for each specification and 300,000 pcs of plough discs and harrow discs. They are exported to more than 66 countries and regions, such as USA, France, Germany, Russia, Switzerland, Zimbabwe, Ukraine, Nigeria, South America .
We will convey the value of Chinese agricultural machinery for the mission, to be world-renowned manufacturer of vision, cooperate sincerely with the partners at home and abroad making bright future.
