MODEL 310HRSS-150
AUTOMATIC FULL SCALE ROCKWELL HARDNESS TESTER
Feature & Use
Automatic tracking and testing, no test error caused by deformation of frame and workpiece
The first test is effective
RS232 data interface
It's suitable to determine the Rockwell & Superficial Rockwell hardness of ferrous metals, alloy steel and hard alloy, as well as treated layers of metal surface, such as carburized layer, nitrided layer and electroplated coating, etc. It's especially suitable to determine heterotypic workpiece.
Specifications
Test force: Rockwell 588.4, 980.7, 1471N (60, 100, 150kgf)
Superficial Rockwell 147.1, 294.2, 441.3N (15, 30, 45kgf)
Measuring scale: HRA, HRB, HRC, HRD, HRN, HRT
(Scales of E, F, G, H, K are optional)
Unit of display: 0.1HR
Moving range of measuring head: 50mm
Output: built-in RS232 interface
Max. height of test piece: 170mm
Depth of throat: 150mm
Dimensions: 535 x 220 x 910 mm
Power supply: 220V AC or 110V AC, 50 or 60Hz
Weight: approx. 100kg
Standard accessories
Large flat anvil: 1 pc.
Small flat anvil: 1 pc.
V-notch anvil: 1 pc.
Diamond cone penetrator: 1 pc.
1/16" steel ball penetrator: 1 pc.
Rockwell standardized block: 5 pcs.
Superficial Rockwell standardized block: 6 pcs.
