Horizontal Double Column Hydraulic Press Machine, YD-3150---ACECARE
US$ 60,000 - 80,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
ACECARE
Usage:
Other, Production Line
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Model: YD-3150 Hydraulic Bottom Press MachineUS$ 60,000 - 80,000MOQ: 1 Set -
YD-3150 Horizontal Double Column Hydraulic PressUS$ 60,000 - 80,000MOQ: 1 Set
-
Nitrogen Booster CompressorNegotiableMOQ: 1 Set
-
YD-3150 Horizontal Double Column Hydraulic PressUS$ 40,000 - 150,000MOQ: 1 Set
-
YD-3150 Horizontal Double Column Hydraulic Press MachineUS$ 40,000 - 150,000MOQ: 1 Set
Place of Origin
Liaoning, China
Brand Name
ACECARE
Usage
Other, Production Line
YD-3150 horizontal Double column hydraulic press parameter
No. |
Name |
Unit |
Model or Data |
|||
1 |
Nominal pressure |
KN |
3150 |
|||
2 |
Inner diameter of main cylinder |
mm |
Φ400 |
|||
3 |
Push force of turning cylinder |
KN |
306 |
|||
4 |
Inner diameter of turning cylinder |
mm |
Φ125 |
|||
5 |
Max.systerms pressure |
Mpa |
25 |
|||
6 |
Single cycle time |
S |
30(non load) |
|||
7 |
Electric motor |
Pc |
30KW×1 |
|||
8 |
Oil pump |
Pc |
160YCY14-1B×1 |
|||
9 |
Press bottom size |
mm |
Φ219-Φ406(bottle wall thickness δmax=10) |
|||
10 |
Operated by |
Semi-auto(PLC control) |
||||
11 |
Overall dimension |
mm |
Main body: |
3850×1340×1970 |
||
Oil tank: |
1200×1000×1200 |
|||||
12 |
Bottom size |
mm |
Max.diameter |
406 |
||
Max.length |
1500 |
|||||
More details, please feel free to contact us.
