Specifications
hydraulic press brake machine1)DRO for back guage and ram stroke
2)CNC can be attached to the machine
hydraulic press brake
hydraulic press brake WC67Y-40/2000 technical datas as following:
Nominal Force :400kn
Length of worktable :2000mm
length of walls :2000mm
Ram stroke :60mm
Opening height :420mm
Amount of ram adjustment :100mm
Distance of back guage :0-400mm (ball screws)
Stroke :12 times/minute
Main power :5.5kw(Siemens,Germany)
power for back guage (ball screw) :0.55kw(Siemens,Germany)
hydraulic system : OMEGA(U.S.A)
electrical system :Siemens(Germany)
power for ram adjust :0.55kw(Siemens,Germany)
MAIN COMPONENTS:
integrated hydraulic system,
hydraulic elements : OMEGA(U.S.A).
digital readout : south korea.
mail motor,main electric parts : Siemens (Germany).
seal:Nok (Japanese).
Guarantee : 14 months from the date of B/L.
Autonics readout and rotary encoder.
CHARACTOR:
1)whole steel-welded,standard upper and lower dies,hydraulic transmission system,foot pedal with emergency stop.
2)The machine equips with DRO(digital readout) system to display the values of ram and backguage,(ball screws),and equip the side and back guard.
to equip CNC system,you can choose the system E-20+ CNC(made in China) or Delem 51 system (from Netherlands),All price include the servo-motor, To equip with light curtains for rear of press brake,you can choose the system from China or sick from Germany.
All include the servo-motor.
To equip with light curtains for rear of shearing machine,you can use system from China madeor sick from Germany.
