Machine type filling machine/ bottle filling machine
1 Brief introduction of bottle filling machine
The machine adopts PLC programmable control, with LCD touch screen man-machine interface system, flow parameters of the atmospheric pressure type, control the time of filling and to realize the different measuring filling.This equipment has simple structure, the size bottle and general, change the bottle shape without changing accessories, can be adjusted.Widely used in juice, soy sauce, vinegar, mineral water, pesticide, chemical, detergent, oral liquid, disinfectant liquid filling, lubricating oil and cosmetics.Filling measurement precision, no bubble, no drop leak.Can be used in the 40-1000 - ml bottle shape (including special-shaped bottle) filling.
Technical parameter
| Model | AF-LF-4 | AF-LF-6 | AF-LF-8 | AF-LF-12 | AF-LF-16 |
| Filling nozzles | 4 | 6 | 8 | 12 | 16 |
| Filling range | 40-1000ml | ||||
| Filling speed(100ml)bpm | 1500-3000bottle/h | 2000-4000bpttle/h | 3000-5000bottle/h | 4000-7000bottle/h | |
| Filling precision | ±1% | ||||
| Air consumption | 180L/t | 200L/t | 200L/t | 0.5m3/t |
0.5m3/t |
| Power supply | 220V 50/60Hz | ||||
| Power consumption | 0.5Kw | 0.5Kw | 0.5Kw | 0.8Kw | 0.8Kw |
| Net weight | 400Kg | ||||
| Overall dimension(mm) | 6000*8002800 | 6000*850*2600 | 6000*850*2600 | 6000*900*1900 | 6000*900*1900 |
Three Advantage
1)The advanced technology
1, this machine is suitable for different specifications of the container filling, switch in a few minutes filling specifications.2, filling cycle is short, high production capacity.3, replace filling specifications without having to add equipment, need to be adjusted.4, touch color screen operation, can according to production condition, operation procedure and the way of filling.5, each filling head of a card bottle device, ensure accurate injection material para.
2)Unique way of filling
1.The design of linear group into the bottle, the bottle way, make filling function extension, eachKind of container, can effective filling in this equipment.2, with international advanced gas filling valve, ensure no drip, no hanging Christmas filling process.3, powerful PLC software support, which can realize the ideal filling operations.4, friendly man-machine interface, and so are completed on the touch screen operation.
3)Precise metering control
1. Filling with fixed port parameters, control the filling time, implement different measuring filling.2, pneumatic valve, filling the precise time can be set to 0.01 seconds, can make the metering accuracy controlIn the scope of error of plus or minus 1%, reduce unnecessary material loss, improve economic efficiency by the user.3, each filling head of measurement can be individually adjusted, so as to realize the consistent filling measurement.4, the machine set into the counting procedures, no bottle, bottle does not reach the designated position is not filling, only whenCounter records to the bottle and set the number of filling bottles is consistent to the filling.5, filling quantity of how many, can be adjusted to the required at the beginning of filling amount, fine-tuning again,Can get ideal filling measuring accuracy.
Details show
1.We always use standard export packing, carton box. But for our customer, Alpha Machine give a free Wooden Package to protect your machines.
2.You can choose express, by air, by train or by sea. Always we will give our best recommend based on our experience.
3. We cooperate with China best shipping company to get best price and fast delivery.
4. You will get full feedback when your machine is on the way.
Our Service:
Pre-sales services
* Any concerns of our machine by email/phone will be replied ASAP within 24 hours
* According to the customers’ requirements and circumstance to make the best design
* Cost/benefit analysis
* To support factory layout
In the sale of services
* We are in charge of installing,debugging and training
* Technical guidance of frequently asked questions
After-sales service
* One year guarantee for whole machine except of quick-wear part
* 24 hours technical support by email/phone
* Calling, network or door-to-door service
* Use friendly English software, user manual and detailed Videos/CD
