Double side sealer shrink wrapping machine L type for sale
contact Helen
mobile/what's app : 0086 13703827012
shype: shuliy0306
Introduction
Our sealing and shrinking machine is a fully automatic unmanned operation "L" type sealing machine which is widely used in mass production packaging line with high efficiency. Automatic film feeding punching device, manually adjustable film-guide system and feeding conveyor platform make the machine suitable for different width and height items.
Sealing knife uses the aluminum knife with DuPont Teflon which is anti-stick coating & anti-high temperature. So the sealing will not have cracking, coking and smoking with zero pollution;
Equipped with imported photoelectric of horizontal and vertical detection for choice to easily finish the sealing of thin and small items;
Automatically-feeding: the length can be auto adjusted by the sensor and time relay. Matched the reduction motor makes the waste film automatically rolling;
Changing molds and bag makers;
Different size products can also be packaged combinations to achieve the promotional effect;
Using original Autonics digital temperature controller which built-in PID function. Sealing blade temperature is extremely sensitive and accurate and we can be arbitrarily set. Do not worry about hurting the product for imprecise temperature. The sealing blade itself is also equipped with automatic protection function which effectively prevent from accidental cutting;
The machine is equipped with organic glass shield with automatic alarm function which greatly improves safety;
The entire machine realizes unmanned operation with the production line connecting;
Film up-down synchronization mechanism specially designed to correct the deviation film;
I can be added easily tear functions according to customer requirements;
Applies to software, food, cosmetics, printing, pharmaceutical, flooring, ceramic, beverages, hardware and other industries’ large quantities of shrink wrap.
parameter
Technical Data |
SL-400L+SLD-450 |
Sealing type |
L-sealing |
Power supply |
380V/50-60Hz/3phase |
Packing capacity |
15 - 35 packs/min |
L-bar sealing size |
570x480 mm |
Sealing height |
150 mm |
Product size |
width + height < 400mm, length + height < 480mm |
Film type |
center-folded polyolefin (POF) film |
Max film size |
530mm (width) x 280mm(outer diameter) |
Oven size |
1200(L) x 450(W) x 220(H) mm |
Shrink tunnel conveyor speed |
variable, max. 40 m/min |
Shrink tunnel conveyor |
rotating silicon coated rods |
Power consumption |
max. 8.5 kW |
Working height |
780-850 mm |
Air pressure |
0.5MPa (5 bar) |
Sealing knife |
Teflon coated alloyed knife with permanently heated bar |
Main control components |
Omron temperature controller, timer, relay and sensor |
Machine main material |
powder coated carbon steel |
Machine dimension |
1600 x 770 x 1450mm 1600 x 600 x 1260mm |
Machine weight |
450kgs |
If you are interested in our product, please feel free to contact me
