Mosquito coil production line/Mosquito coil machine/Mosquito coil maker//0086-13703827012
Mosquito-repellent incense machine
1.Mosquito-repellent incense machine
2.the production scale is according to the production lines
1.Large mixing: mix all raw materials together, and get ready to next grout mixer.
2.Grout mixer: put starches into the machine, cook the starches by boiling water
or steam.
Using water or steam Jie Ke, mixing pulp evenly.
Specifications
Motor Power: 1.5KW
Capacity: up to 50 kg each
Overall: φ900mmx1700mm
3.Small mixer: put the raw materials which are mixed by the first step and the starch
es that it is cooked together , and then they are called the wet green.
This machine has a design and generous, simple operation, easy maintenance,
automatic reversing feed and so on. Stir in hand to install a simple, durable wear-
resistant, weldable change, reduce production costs.
Specifications
SLJB-B100
Motor Power: 5.5KW
Capacity: up to 100 kg per mixing
Homogenization time: 12 minutes
Dimensions: 2300mmx1100mmx1300mm
SLJB-B200
Motor power: 11KW
Capacity: up to 200 kg per mixing
Homogenization time: 12 minutes
Dimensions: 2800mmx1300mmx1300mm
4.The forming machine: put the ready mixed wet greens into the forming machine.
After going through the second pressure, it will form the mosquito wet-green.
Production efficiency: 22680 / hour (in 18-mode as an example)
Motor total power: 27.65KW
Operator: 4 people
Sieve plate size: 900mmx450mmx40mm
5.The drying room:push the mosquito wet-green into the drying room, dewater, drying for a while , and then it is the mosquito
dried-green. ( this is a local building)
6.Automatic mosquito-repellent molding machine: the machine will collect the mosquito-repellent incense automatically. And will get ready to next step: spraying.
7.Automatic piece-distribution machine: collect the mosquito-repellent incense
together , and send them into the next step.
8.Stainless steel chemical spray of SLPY-300 types:
when the mosquitos come in this machine, the machine will spray the
chemical drugs onto the mosquito-repellent incense, in order to kill the mosquitos.
Motor Power: 1.2KW
Spraying rate: single 150 / min dual-channel 300 / min
Dosage error: ± 5%
Overall: 2300mmx650mmx1200mm
9.Assemble:put the mosquito-repellent incense into the package, then into the carton, and collect them into the
warehouse.
product show:
if you are interested in this machine,please contact me:
