best quality horizontal mixing machine
I.Description
Batch type ribbon mixers are of wide application and high efficiency. Horizontal, single shaft with double proportioned ribbon is housed in the tubular mixing drum. The vortex ribbon rotates with main shaft and thus bring raw material move towards direction of vortex ribbon. We can design round or rectangular shape inlet port on top cover, discharge valve (manual, pneumatic or electric driven) in middle of bottom. The vortex structure of outer ribbon combined with rotation of main shaft drive material to discharge outlet guaranteeing no dead corner.
II.Principle
The vortex outer ribbon combined with rotation direction drive material from two ends to Centre; at the same time, inner ribbon drive material from Centre to two ends. Materials are evenly mixed at shortest time. Ribbon mixers are widely used in dry powder, granule, liquid and paste with low viscosity.
The main technical parameters:
Model |
Voltage |
Power |
Mixing barrel thickness |
Mixing capacity |
Size of the mixing barrel |
weight |
Mixing device |
FOB Price |
||
ribbon |
screw shaft |
bearing bracket model |
||||||||
SLMJ-500 |
380V/50HZ |
5.5kw |
2mm |
500kg/batch |
1.26*0.73*0.85m |
400kg |
6mm |
65mm |
210 |
|
SLMJ-1000 |
380V/50HZ |
7.5kw |
3mm |
1000kg/batch |
1.8*0.9*1.05m |
950kg |
8mm |
90mm |
212 |
|
SLMJ-2000 |
380V/50HZ |
11kw |
3mm |
2000kg/batch |
2.2*1.2*1.35m |
1200kg |
8mm |
90mm |
212 |
|
