factory price and made in china veneer peeling machine
0086-13503826925
the introduction of veneer peeling machine
1)Advanced control system , this wood debarking machine is contralled by servo syaterm,it is a more advanced syaterm than PLC control,it isclosed loop control,which will not be noninterference by courter eleectromagnetic,and have a better performance in location control,then the veneer will comes out better.
2)Suitable for large diameter logs , the max peeling diameter for this machine is 380 mm , which is larger than normal Spindle-less peeling machine , veneer thickness range is from 0.4-3.6 mm ,
The advantage of veneer peeling machine
1)High efficiency , the peeling speed of this machine is 43m/min , which is the most efficient machine among all the peeling machines.
2)Easily operated , the control box is touch screen , you can adjust the parameters by touching the screen .
3)knife table angle adjustable , this is our patent technology , which can help to make the veneer smooth better.
The specification of veneer peeling machine
Model |
TZG1350/3 |
TZG1350/4 |
TZG2600/3 |
TZG2600/4 |
Max.cutting length (mm) |
1350 |
1350 |
2600 |
2600 |
Max.cutting diameter (mm) |
360 |
360 |
360 |
360 |
Log-core diameter (mm) |
40 |
40 |
40 |
40 |
Cutting thickness (mm) |
0.8 - 3.0 |
0.8 - 3.0 |
0.8 - 3.0 |
0.8 - 3.0 |
Veneer output speed(m/min) |
42 |
42 |
42 |
42 |
Power (kw) |
21.7 |
20.6 |
29.2 |
28.1 |
Overall dimensions (mm) |
3450*1950*1700 |
3380*1900*1600 |
4650*1950*1700 |
4650*1900*1600 |
Weight (kg) |
7500 |
7000 |
9500 |
8500 |
The picture of veneer peeling machine
Pre-sales services
* any concerns of our machine by email/phone will be replied ASAP within 24 hours
* according to the customers’ requirements to suggest best machine
*we can provide the video of our machine
* to support factory layout
In the sale of services
* to inform you every steps about delivery
* delivery the machine as soon as possible
After-sales service
* one year guarantee for whole machine
* 24 hours technical support by email/phone
