Help CenterENiCu-7 Welding Electrode Diameter 3.2mm
Related Products
-
ENiCu-7 Welding ElectrodeUS$ 100 - 100MOQ: 5 Kilograms -
ENiCu-7 Welding Rod Diameter 4.0mmUS$ 100 - 100MOQ: 5 Kilograms
-
ENiCu-7 Welding Rod Diameter 3.2mmUS$ 100 - 100MOQ: 5 Kilograms
-
ENiCu-7 Welding RodUS$ 100 - 100MOQ: 5 Kilograms
-
ERNiCrCoMo-1 Welding Wire Diameter 2.4mmUS$ 100 - 100MOQ: 5 Kilograms
MONEL Welding Electrode 190 is used for shielded-metal-arc welding of MONEL alloys 400, R-405, and K-500. It is also used for surfacing of steel. The weld metal is resistant to corrosion by sea water, salts, and reducing acids. The electrode is capable of producing weld deposits that meet stringent radiographic requirements. Although the electrode produces sound joints in MONEL alloy K-500, the weld metal has lower strength since, unlike the base metal, it is not age hardenable. Dissimilar-welding application for MONEL Welding Electrode 190 include joints between MONEL nickel-copper alloys and carbon steel, low-alloy carbon steel, copper, and copper-nickel alloys.
The electrodes provide excellent operability for groove and fillet welding in the downhand position and the smaller diameter electrodes are also suitable for all position welding. Power supply: direct current, electrode positive.
Specifications
AWS A5.11 ENiCu-7(UNS W84190)
ASME II, Part C, SFA-5.11, ENiCu-7(UNS W84190)
ASME IX, F-No.42
DIN1736 EL-NiCu30Mn(2.4366)
(EN)ISO14172-ENi4060(NiCu30Mn3Ti)
Supply to these specifications available upon request
For manufacture to ASME III(NCA3800, NB2400), MIL and other specifications please refer your inquiry to the technical department prior to order placement.
Approvals
VdTUV 2106.01
Other approvals may be applicable, please confirm details of current scope of approvals with the technical department prior to order placement.
Limiting Chemical Composition
Ni+Co |
C |
Mn |
Fe |
S |
Cu |
Si |
Al |
P |
Ti |
Others |
62.0-68.0 |
0.15 max |
4.0 max |
2.5 max |
0.015max |
Remainder |
1.0max |
0.75 max |
0.02 max. |
1.0 max |
0.50 max |
Minimum mechanical properties
Tensile strength, psi 70,000
Mpa 483
Elongation, 4d% 30
Filler metals available on spool and in cut straight lengths in a variety of sizes selected from the following diameters:
Available Product Forms-Supplied in 10lbs(4.54kg) hermetically sealed containers
Diameter |
mm in |
2.4 3/32 |
3.2 1/8 |
4.0 5/32 |
4.8 3/16 |
Length |
mm in |
229 12 |
356 14 |
356 14 |
356 14 |
Current(DC+) |
A |
55-75 |
75-110 |
110-150 |
150-190 |
