Home > Products > SUS321 317L SUS347 > ASTM A193 B8C Socket Head Screw Allen Bolts AISI347
ASTM A193 B8C Socket Head Screw Allen Bolts AISI347
- SHANGHAI
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | xdo | |
| Model Number | as drawing | Standard | DIN |
Product Description
Specifications
316L ,317L . 904L, 1.4529, 724L ,PH17-4. , 310S, 309S . 254SMO, 316TiInconel : Inconel600, Inconel718, hastelloy C276
ASTM A193 B8C socket head screw allen bolts AISI347
Chemical Composition
| SS 347 | SS 347H | |
| Ni | 9 – 13 | 9 – 13 |
| Cr | 17 – 19 | 17 – 19 |
| C | 0.08 max | 0.04 – 0.10 |
| Mo | 3 – 4 | 3 – 4 |
| Fe | Balance | |
| Mn | 2 max | 2 max |
| Si | 0.75 max | 0.75 max |
| S | 0.03 max | 0.03 max |
| P | 0.045 max | 0.045 max |
| Co + Ta | 10xC min 1.00 max | 8xC min 1.00 max |
1.Size and type:
Bolt: M6-M64
Nut: M6-M64
Threaded Rod:4-2000mm
heavy hex bolts and nuts with all sizes are also available.
2.Materials option: Stainless Steel C276, 904L, 304, 304L,310S, 316, 316L, 321, 317L, 2507, 2205, 254SMO, AL6XN, 1.4501,1.4529.
Super duplex stainless steel F55, F51,F53 HastelloyB&C, Inconel, Incoloy etc.
3.Standards: GB ,ANSI/AMSE, DIN, JIS and BS, etc.
4.Packing : Plywood case or wooden box
5.Exported countries:United States, Germany, Saudi Arabia, South Korea,etc.
In stock items:
310S Hex nuts M6 - M20
AL6XN hex nut M6
904L Hex nuts M6 to M20,
SAF2205 Hex nuts M6 to M20
Hastelloy hex nuts M10
Hastelloy hex nuts M16
Hastelloy spring washer M16
Metric size: M6 to M100
Inch size : 1/4" to 2 1/2
Nut: M3-M64 (hexagonal, flange)
Threaded Rod:4-3000mm (all thread, double end thread)
Packing : Plywood case or wooden box
Payment:L/C T/T
Exported countries:Germany, UK, South Asia, Chile, Canada, Pakistan, South Korea,domestic market etc.
Our Feature:
1.Fast Delivery
2.Factory sales
3.small order accepted (50 pieces)
4.mill test certifecate can be provided
5.ISO9001 certificate
