Incoloy825 UNS N08825 EN2.4858 alloy825 cashew nut M20 Incoly800, alloy800
2.4858
Material No. |
2.4858 |
EN symbol (short) |
NiCr21Mo |
UNS |
N 08825 |
AFNOR |
NC 21 FeDU |
BS |
NA 16 |
alloy |
Alloy 825 |
Registered work's labelen |
Incoloy® alloy 825 ; Nicrofer® 4221 |
Standards |
VdTÜV 432 |
Description
The high corrosion-resistant alloy 2.4858 (alloy 825) is chiefly used in the offshore and chemical industries.
Our product range in 2.4858 (alloy 825) are bolts and nuts ,washers and threaded rods etc.
Chemical composition ¹ | ||||||||
C |
Si |
Mn |
P |
S |
Cr |
Mo |
Ni |
V |
0,025 |
0,5 |
1 |
0,25 |
0,15 |
19,5-23,5 |
2,5-3,5 |
38,0-46,0 |
- |
Nb |
Ti |
Al |
Co |
Cu |
Fe |
|
|
|
- |
0,6-0,12 |
1,20 |
1,0 |
1,5,-3,0 |
Bal |
|
|
|
¹ in accordance with Key to Steel 2001 | ||||||||
Special characteristics | ||
Temperature range |
Density kg/dm³ |
Hardness (HB) |
-10°C bis 450°C (pressure vessel up to 425°C) |
8,1 |
|
high-corrosion resistant nickel-based alloy | ||
| Fastener Type | bolt&nut/screw/stud bolt//threaded rod/washer | |
| Bolt | Type | Hex head bolt; hex socket head bolt; square head bolt; U-bolt; T-bolt; round head bolt;Machine bolt; expansion bolt; CSK Head square carriage bolt; eye bolt; |
| Specification | Threads diameter: M6-M64. length: 10mm-500mm | |
| Standard | DIN931;DIN933;DIN975;DIN976;DIN915;DIN316;DIN444; DIN580; DIN916; DIN914; DIN913; DIN912 | |
| Screw | Type | hex screw; hex socket cap screw;hex socket countersunk head screw |
| Specification | M6-M64 length: 6-500mm | |
| Standard | DIN913; DIN912; DIN 7984;DIN 933; DIN84; DIN85; DIN7972; DIN694; DIN7971; DIN7973 | |
| Nut | Type | Hex nut;square nut; wing nut; weld nut; Coupling nut; Cap nut; flat nut; lock nut;half nut; full nut; |
| Specification | M6-M64 | |
| Machining | CNC turning, , CNC milling, CNC drilling and CNC boring by vertical CNC machine and Horizontal CNC machine | |
| Standard | DIN 934; DIN 439; DIN315; DIN985; DIN928; DIN929; DIN582; DIN6334; DIN917 | |
| Washer | Type | Plain washer; flat washer; spring washer;square washer; slant washer; wave washer |
| Specification | M6-M64 | |
| Standards | DIN125, DIN435, DIN9021, DIN433, DIN440R, DIN1440,DIN1441, DIN93, DIN7349, DIN1052, DIN988; DIN7603; DIN137A, DIN137B; DIN6769; DIN6797J; F436; DIN6798V; DIN 127B,ANSI18.21.1,DIN127A,DIN7980; DIN6798J;DIN6798A;ROUND WASHERS WITHOUT HOLE,BS4320 F/B,NFE25514Z/M/L/LL, IFI NARROW/WIDE | |
