Small coal gasifier/ coal gasifier/ Coal Gas Producer/ coal gas generator/ coal gasification/ china coal gas producer furnace/ coal gasifier plant
Condition: | New,new | Place of Origin: | Henan China (Mainland) | Brand Name: | SHULIY |
Model Number: | SL series | Usage: | heating | Production Rate: | 6-27 KW |
Certification: | CE, ISO9001:2008,SGS | Warranty: | 12 months | After-sales Service Provided: | Overseas service center available |
Type: | one stage coal gasifier | Color: | Customized | Certificate: | ISO9001:2008 & CE |
Warrant period: | 12 months | Efficiency: | high | Quick wear parts: | we offer |
Service time: | whole using life | Brand: | SHULIY | ||
Packaging & Delivery
Packaging Detail: | 1.Naked 2.Packed in wooden box 3.to requirement |
Delivery Detail: | 10-30 days after receiving prepayment |
Specifications
One stage coal gasifier
Energy saving, high efficiency
Stable performance
12 months warranty
ISO9001:2008 & CE approved
Famous energy-saving one stage coal gasifier in fair price
Usaging of one stage coal gasifier
The one stage coal gasifier products designed and made by our company takes air and steam as gas agent, it is an advanced equipment for producing gas, It is suitable for gasifying charred coal, coke. And it is widely used in heating furnace in machinery, metallurgy, chemical engineering, glass, building materials, light industry, food and textile.
Advantages of coal gasifier
Firstly, It can raise the utilization of heat and coal can be fully burnt, so the energy comsumption can be reduced. Compared with burning the coal directly, It can save 20%-40% energy.
Secondly, By using this equipment, the temperature can reach 1500°C in the connected kiln or furnace and the temperature difference is low.
Thirdly, It is conforming to the industrial furnace emission standard GB9079.88. Slag is discharged in wet form which is free from pollution and social benefits.
Fourthly, It can greatly improve the working environment, reduce the labour intensity, so it has been well-received since it was invented.
Main technical parameter of one stage coal gasifier
Model | SL0.8 | SL1.0 | SL1.2 | SL1.5 | SL1.6 | SL1.8 | SL2.0 | SL2.4 | SL2.6 | SL3.0 | |
Name | Unit | Producer furnace specification | |||||||||
Chamber diameter | mm | 800 | 1000 | 1200 | 1500 | 1600 | 1800 | 2000 | 2400 | 2600 | 3000 |
Heating active surface | m2 | 0.5 | 0.785 | 1.13 | 1.77 | 2.01 | 2.54 | 3.14 | 4.52 | 5.31 | 7.07 |
Fuel | Weak coherent gas carbon, anthracite, burnt carbon | ||||||||||
Fuel granularity | mm | 25-80 | |||||||||
Fuel consumption | kg/h | 40-100 | 70-140 | 120-190 | 160-350 | 350-460 | 500-600 | 500-720 | 700-1040 | 850-1200 | 1700-2000 |
Gas agent | Air, steam | ||||||||||
Gas output | Nm3/h | 140-350 | 245-490 | 420-670 | 560-1200 | 1200-1600 | 1500-2100 | 1750-2500 | 2500-3600 | 3000-4300 | 6000-7000 |
Coal gas calorific value | Kj/Nm3 | 5020-5670 | 5020-6000 | ||||||||
Water jacket heating area | m2 | 4.02 | 5.02 | 6.78 | 10.37 | 11.06 | 12.44 | 17.58 | 21.87 | 23.69 | 30.16 |
Steam output | kg/h | 60 | 80 | 130 | 200 | 220 | 260 | 350 | 420 | 600 | 840 |
Temperature of coal gas outlet | °C | 400-500 (Plants related with the coal) | 400-500 (Plants related with the coal) | ||||||||
Pressure of coal gas outlet | Pa | <1000 | <980-1470 | <1470-1960 | |||||||
Diameter of coal gas exportation | mm | 219 | 325 | 325 | 426 | 426 | 529 | 630 | 720 | 820 | 1020 |
Air pressure | Pa | <3000 | <4000 | ||||||||
Temperature of saturated air | °C | 50-60 | 50-65 | ||||||||
Rotational speed of disc | r/h | 0.177-1.77 |
|
| |||||||
Total weight of equipments | T | 3.5 | 4.5 | 5 | 7.5 | 10 | 20 | 23.4 | 29.8 | 32 | 37.6 |
Power of complete equipments | KW | <6 | <6 | <6 | <7 | <8 | <10 | <14 | <20 | <20 | <27 |
Diameter of tuyere | mm | 108 | 108 | 140 | 165 | 219 | 325 | 325 | 426 | 426 | 426 |
