Stainless Steel Horse Feed Pellet Mill

Wooden case/20GP

Specifications

Horse feed pellet mill
1.Capacity 2-10t/h
2.Imported bearing
3.Pellet dia 1-10mm
4.CE Approved

Stainless Steel Horse Feed Pellet Mill



Animal Feed Pellets Raw Material:

The main material is maize, wheat, rice, beans, sorghum, oats etc.. And can add little grass, alfalfa etc..



Main Characteristics

1)    This series machine suitable for making all kinds of animal feedstuff. Which capacity 1-20t/h for feed factory .

2)    The machines can be match different size of ring die hole size , such as φ1.0, φ1.2, φ1.5,φ2.0, φ2.5, φ3.0, φ3.5, φ4.0, φ4.5, φ5.0, φ6.0, φ8.0, always for making shrimp, fish feed to use for φ1.0--3.5 ring die ; chicken feed for φ3.0; Swine feed for φ3.0--4.5; Cattle, horse for φ6.0--8.0).

3)    The machine adopt imported bearings, the motor brand is China famous brand.

4)    Driven by gear, more strong than by belt, and the capacity 10% higher than by belt .

5)    The machine also matched the safety device, once overload, the safety pin will crack, to protecting the machine lifetime.

6)    It has low noise during the production.

7)    And its feeder can be regulated a variable speed controlled to meet different outputs requirements.

8)    It is with magnet and overload protection system, which can protect machine well during production

9)    We have oversized conditioner and jacked conditioner for choosing to enhance the effect of the pellet condition.



Details and Spare Parts of horse feed pellet mill



Main Technical Parameter

Model	Capacity	Main Power	Feeding Power	Conditioner Power	Ring die inner diameter
AZS-SZLH250	1-2t/h	22kw	0.75kw	2.2kw	φ250mm
AZS-SZLH320	2-5t/h	37kw	0.55kw	2.2kw	Φ320mm
AZS-SZLH350	2-8t/h	55kw	0.75kw	2.2kw	Φ350mm
AZS-SZLH400	2-10t/h	75/90kw	0.75kw	2.2kw	Φ400mm
AZS-SZLH420	3-12t/h	110kw	1.5kw	5.5kw	Φ420mm
AZS-SZLH508	4-20t/h	132/160kw	1.5kw	7.5kw	Φ508mm
AZS-SZLH558	6-22t/h	160/180/200kw	2.2kw	7.5kw	Φ558mm
AZS-SZLH678	10-30t/h	220/250kw	2.2kw	11kw	Φ678mm
AZS-SZLH768	12-35t/h	280/315kw	2.2kw	15kw	Φ768mm



Different model of horse feed pellet mill



Final Animal Feed Pellets

Making different animal feed pellets, such as chicken feed, cattle feed, rabbit feed, fish feed, shrimp feed etc.



Complete Animal Feed Pellet Production Line

The main process of the pllet line includes: (Material storage System)-- Material receiving System-- Crushing System-- Mixing System-- Pelletizing &Cooling System-- Packing System





Our Factory Show



Please do not hesitate to contact BELLA WU, if you need any more information or have any other questions. We will be at your service at any time.
