Chalk Machinery gypsum powder chalk processing equipment

wooden case or as per customers' request

Specifications

gypsum powder chalk processing equipment
1. very efficiencent
2. quite easy to operate
3. mould number:1 to 8

Chalk Machinery gypsum powder chalk processing equipment



Chalk making procedure:

 1*. Slaked Lime mixer, power on, then fill in the water.

      The rate for the slaked lime and water is half to half.

2*. The mold should be lubricated enough. And should be lubricated for every cycle

3*. Each model has 80 spaces for the filling, each cycle will be take about 6minutes,

4*. When the filling completed, should be turn off the model make the wet chalk come off from

      the model, then dry in the sun.

5*. The packing should be completed by handwork.

6*. The shape can be round, rectangle, or star shape.

      The length of the chalk can be from 75mm-105mm.



Technical Parameters of gypsum powder chalk processing equipment:

Model	Capacity (pcs/h)	Mold Specification (pcs/ mold)	Packing dimensions (mm)	Mold number	Weight (kg)	operator
AZSCM401	2000-4000	400	530*380*340	one	30	One
AZSCM801	4000-8000	800	660*480*360	one	65	One
AZSCM802	8000-12000	800	1800*1150*800	two	260	One
AZSCM804	12000-24000	800	1800*1150*800	four	350	One
AZSCM806	24000-32000	800	1800*1150*800	six	600	two
AZSCM808	32000-48000	800	1800*1150*800	eight	800	three

Remarks:

Chalk dimensions: 10mm (big head)×8mm (small head)×75-105mm(length)

The mold capacity can be as per customers’ request

Chalk shape: round, rectangle, star or as per customers’ request



Your best partner on chalk making equipment:

Chalk Machine operation video is available~







Any requestments, please contact us:
