AFS25 Foundry ceramic sand Fused ceramic foundry sand Spherical foundry sand for casting
Description of Foundry sand
Foundry sand is a kind of refractory particle with diameter of 0.053-2.0mm.
Mainly made of Al2O3·SiO2. It is ball-shaped particle made from bauxite
by high-temperature melting in electric-arc furnace, spraying and cooling.
Application of Foundry sand:
1.Widely used in foundry technique like resin-bonded sand, sodium silicate sand, and clay- bonded sand for sand core and casting mould making.
2.Replace chromite sand and widely used in sand core making like jacket core, oil duct core, tappet core of engine.
3.Replace chromite sand for steel casting facing sand and sub-layer of molding sand (backing sand).
4.Widely used as dry sand and sand box for EPC process and V method of casting processes.
5.Widely used as the main raw materials of advanced refractory products (Ladle drainage sand,gravity casting material, casting coating, etc.).
6.Widely used as cleaning sand for copper and aluminum alloy castings.
Advantage of Ceramic foundry sand:
1, Perfectly round shape with higher fluidity improves fill-in efficiency while reducing the resin leve
2, Smooth surface of spherical shape greatly improves collapsibility after pouring
3, Very low thermal expansion ensures fewer or no casting defects such as veining and deformation
4, Excellent thermal conductivity and heat absorption capacity close to that of Zircon
5, Superior refractory equivalent to Zircon and Chromites
Specification:
Ceramic foundry sand for casting and precision casting
Purpose | Specification | Chemical composition(%) | Bulk Density : 2.0g/cm3 Min True specific gravity: 2.70g/cm3 Min | ||
Al2O3 | Fe2O3 | Na2O+K2O | |||
Casting | AFS20-AFS120 | 70-75% | 5.0% Max | 1.0% | |
75%min | 2.5% Max | K2O:0.50%max | |||
specification | mesh | 10 | 14 | 18 | 26 | 36 | 50 | 70 | 100 | 140 | 200 | 281 | Pan |
|
um | 1700 | 1180 | 850 | 600 | 425 | 300 | 212 | 150 | 106 | 75 | 53 | Pan |
| |
AFS:20 |
| ≤5 | 10-30 | 30-50 | 15-35 | ≤5 |
|
|
|
|
|
|
| |
AFS:30 |
|
| ≤6 | 10-20 | 30-50 | 15-35 | ≤10 | ≤5 |
|
|
|
| 25-35 | |
AFS:40 |
|
|
| ≤5 | 0-20 | 20-40 | 20-40 | 10-30 | ≤10 | ≤2 |
|
| 30-55 | |
AFS:50 |
|
|
| ≤3 | ≤15 | 25-40 | 25-40 | 10-20 | ≤10 | ≤5 | ≤3 |
| 45-55 | |
AFS:60 |
|
|
|
| ≤10 | 10-30 | 30-50 | 15-25 | 0-20 | ≤5 |
|
| 55-65 | |
AFS:75 |
|
|
|
|
| ≤10 | 5-25 | 25-45 | 20-40 | ≤10 | ≤5 |
| 75-85 | |
AFS:100 |
|
|
|
|
|
| ≤3 | 10-30 | 35-55 | 15-35 | ≤10 | ≤2 | 105-115 | |
AFS:125 |
|
|
|
|
|
| ≤2 | 0-20 | 30-50 | 25-45 | 0-20 | ≤5 | 125-135 | |
AFS:150 |
|
|
|
|
|
|
| ≤5 | 5-25 | 40-60 | 25-40 | ≤15 | 160-170 | |
Particle size :AFS 20-AFS120
Packing: 1 MT big bag or 25kg paper bag *40 bags on one pallet ;As per customer’s requirement
Remark: specification and size can be optimized
by per customer' requirement
Our company :HENAN RUISHI INVESTMENT GROP
Productive Process:
Q1. Will the FREE SAMPLES be provided for buyers?
- YES. We will provided FREE SAMPLE about 1kg
Q2. How about the express fee?
- Our company’s policy is the buyer pay for express fee.
Q3. Is there QUALITY REPORT for the products?
- YES. We provide quality report of our company or CIQ,SGS according to client‘s requirement
Our Sincere Service
1.Customized size and packing are available on customers' requests.
2.Manufacturer with large capacity,ensures the fast production cycle
after confirming the order.
3.Protection of sales area and private information for all of our customers.
