Lab type roll grinding machine/paste roller grinding machine/food roller grinding machine for chocolate
1. function
The three rollers will push & press each other, and generate a strong frication to disperse and grind materials. It is widely used in battery paste industry.
1. With imported oil pump, hydraulic automatic control
2. Tension and release of inlet/outlet, material viscosity both with hydraulic control
3. Special alloy material for roller, high hardness and wear resistant
4. Rational structure with plank frame for hydraulic system
5. Suitable for paste shape material with high viscosity
2. machine application
three-roll grinding machine for seeds is widely used for high viscous material grinding, like printing ink, pigment, soap, plastic, lube grease, chocolate etc.
3. technical parameter
Model | Roller dia.(mm) | Roller length(mm) | Quick/Mid/Slow roller speed(rpm) | Motor power(KW) | Overall size(mm) | Wight(kg) |
ASL-65 | 65 | 125 | 145/70/26 | 0.75 | 410*550*450 | 85 |
ASL-150 | 150 | 300 | 145/70/26 | 2.2 | 1010*930*1000 | 550 |
ASL-260 | 260 | 675 | 155.3/54.5/19.1 | 7.5 | 1645*1350*1000 | 2200 |
ASL-405 | 405 | 810 | 135.5/44/14.25 | 15 | 1950*1950*1300 | 5200 |
ASL-405l | 405 | 1000 | 135.5/44/14.25 | 22 | 2150*1950*1300 | 5500 |
4. machine photo
Zhengzhou Aslan Machinery Co.,Ltd established in 2014 , our company are new in international market ,but we are not new in international market , all member of our company are experienced in international business. Best service, high quality machines are we can service for you. We know we are young but we are confidence, we have more time, more vigor, and more earnest serve for you. Besides that we have powerful supporter, professional technical term together with you and us.
We specialized in machines export and import business. Our products include food machines, agriculture machines, and meat processing machines and so on. For potato processing machine, which include potato harvest machine, potato washing and peeling machine, potato sorting machine and packing machine .For meat processing machine include meat washer, meat chopper, meat bowl cutter, meat tumbler and meat deboning machine, meatball making machine and so on. Quality is our life and your trust is our power. Good cooperating start from trust. We are Looking forward to our cooperation.
•A:Guarantee time is for one year from Machine arrive customer sea port. for every export machine we buy insurance for it . if machine lost or broken during sea freight . we take responsible for it .
Q: During Guarantee time , if machine broken by machine design ,what should we do?
•A:during guarantee time , if machine broken by machine design fault , we talk all responsible , for machine broken part free charge send to you , if after change broken part machine can not work , we send new machine to you .
Q: Which kind documents your company can provided?
•A:after ship depart from China port ,we can get documents from Shipping company such as : bill or lading , insurance documents.packing list , commercial invoice . if you need , we also can apply CO ,FORM F, FORM E etc.
Q:After guarantee time , if we need spare parts , can you provided it ?
•A:we can provided for the machine spare part .
Q:Which kind of package you will use ?
•A:For export , we usually use plywood box . which meet export standard.
