automatic pillow filling machine/fiber filling machine/plush toy stuffing machine
Introduction of automatic pillow filling machine
This machine, it is PP cotton stuffing into the plush toys, sofa cushion, pillow, or pillow core leather machinery and equipment.Generally applicable to plush toys, home textiles, furniture and clothing industries.
Do casing pipes, commonly used cotton filling machine for plastic and spray paint surface treatment, internal mixing device, the following is equipped with a small storage tanks, front foot switch device.Use cotton absorption machine or other equipment first PP cotton, pearl cotton, plastic particles, foam material, or other fillings into the cotton filling machine, filling material can fully stir up inside the cotton filling machine, stepping on foot switch, using the impulse of the gas filling into to the required for filling in the product leather case and finished filling process.
Cotton filling machine according to the discharging mouth can separate two single head and double head, according to the foot switch can be divided into mechanical valve cotton filling machine and electronic valve cotton filling machine.
Features of automatic pillow filling machine
1. High efficiency. A double head filling cotton machine can complete 10 to 15 people work, using cotton filling machine can greatly reduce labor costs.
2. The products are of good quality.Use cotton filling machine filling products full uniform, feel is much better than artificial fill.
Technical parameter of automatic pillow filling machine
Model |
ASL-Single head |
ASL-Double head |
Capacity |
90kg/h |
180kg |
Overall Dimension |
2100*810*1900mm |
1600*1250*2000mm |
Power |
1.5KW |
1.5KW /2.2KW |
Rated Voltage |
380V 50HZ |
380V 50HZ |
Net Weight |
350kg |
550kg |
Air compressor |
7.5kw |
11kw |
Pressure |
8kg |
8kg |
Remark: For this machine need an air compressor, you can buy one in local market | ||
Photos of automatic pillow filling machine
Final product
About after sell service for our Aslan machinery co.,ltd
usually machine guarantee time is about 1 year . Within guarantee time. Machine breaking caused by machine itself
design defect , we are responsible for it .we can provided free charge breaking part, .If machine breaking caused by
humane factor , user need take responsibility for it , we will provided technical support .
About goods shipping of our Aslan machinery co.,ltd
We have long time working shipping forwarder. We can do our best to send machine to your port safe and sound .
If your need , we can help you do custom clearance .
About payment term for our Aslan machinery co.,ltd
Currently, in order to protect you and us rights .both us in safe , hope we can do business in safe way .
L/C(>20000USD),Western Union,T/T(bank transfer),Escrow
which one is you want , we can discuss it .
About our online Service:
24 hours online to solve any problem . Your email will be reply within 12 hours . Your satisfy is our pursuit .
sincerely hope our cooperation.
Contact information:
Contact :Larry He
Skype:Larry.he3
QQ:2746542104
Tel:86-18939526905
Fax:0086-371-53392380
Email:larry@aslanjixie.
com
Any questions if you have, please do not hesitate to tell us.
Your satisfaction is what we are always struggling for!
