frozen meat dicing machine/meat dicer/automatic meat cube dicing machine/meat cubing machine
Introduction of frozen meat dicing machine
This machine is reference to international advanced mechanical design and manufacturing, the structure is reasonable.Cutting of diced minimum specifications for the 4 mm, maximum specifications for 120 mm, is the first choice for food processing and cutting, cutting equipment;This machine can cut the frozen meat, fresh meat products, such as the temperature of the frozen meat in - more than 6 degrees.
Knob, adjust the cutting thickness, make RouLiao push rod for changes in the rate of advance, in order to meet the requirements of different cutting thickness.
Preloading adjustment knob, can guarantee the product in the process of cutting is consistent.
, adjust RouLiao push rod for stepping movement, using the single edge cutting can minimize when in the cutting process of the extrusion products.
Features of frozen meat dicing machine
1. The whole machine adopts full stainless steel design, appearance for sandblasting.
2. Material groove can be fully open, convenient cleaning.
3. The unique design of side plate squeezing effects for the material, the cutting effect is better.
4. The reducer adopts import bond deceleration machine in Taiwan.
5. The main components of the hydraulic pressure station of Taiwan imports.
6. The machine frame body is 3 mm thick stainless steel plate bending welding, cutting parts tear open outfit is convenient, easy to clean.
7. Big blade for 4 chromium silicon material, small blades for 3 chromium silicon material, tool post for 304 stainless steel design.
Technical parameter of frozen meat dicing machine
Model | ASL-DRQDJ-350 | ASL-DRQDJ-550 |
Capacity | 500-600kg/h | 700-900kg/h |
Cutting slot size | 84*84*350mm | 120*120*550mm |
Power | 1.5kw | 2.25kw |
Cutting size | 5,6,7,8,9,11,13,16,20,27,30mm | 5,6,7,8,9,12,16,24,30mm |
Dimension | 1480*800*980mm | 1940*980*1100mm |
Weight | 500kg | 700kg |
Photos of frozen meat dicing machine
Final product
Contact information:
Contact :Larry He
Skype:Larry.he3
QQ:2746542104
Tel:86-18939526905
Fax:0086-371-53392380
Email:larry@aslanjixie.
com
Any questions if you have, please do not hesitate to tell us.
Your satisfaction is what we are always struggling for!
