waffle biscuit stacker/biscuit stacking machine
1. Introduction of waffle biscuit stacker
This machine is mainly to stack the biscuits, packed cookies, bagged waffle for other packing. It is a new generation of device which makes the cooled biscuit stand vertically and orderly arrange in a multi-row.if can effectively improvethe wark efficiency of biscuif packing.Adopt the advanced transducer forstepless speed regulating.The speed is stable and the machine can highly save the energy.it It is equipped with magnetic attachment biscuit pieces which can quickly adjust width.The special structure design is suitable for the biscuits with super thinness and different sizes.
2. Features of waffle biscuit stacker
1.Photo sensor , stepper motor, imported electric componencts create good quality and stable performance
2.Capacity is 0 to 300 packet/min.
3.Adjustable. The range of products is L*W*H=(50-150)*(35-100)*(5-60)mm. If product is larger or smaller than the range, a tailor machine can be made according to your requirement.
4.2 or 3 workers are enough for biscuit boxing and bagging. Save much labor cost.
5.Stainless steel cover, which is more durable.
6.high efficiency
7.time and labor saving,greatly reduce the labor cost.
3. Technical parameter of waffle biscuit stacker
Model |
ASL- Z110 |
ASL-Z120 |
Material |
Partial stainless steel |
Stainless steel |
Capacity |
0~280 /min |
0~300/min |
Packet thickness |
5~30 mm |
5~60 mm |
Packet height |
50~150 mm |
50~150 mm |
Packet width |
35~100 mm |
35~100 mm |
Dimension |
1740*530*800mm |
1740*530*800mm |
Voltage |
220v |
220v |
Frequency |
50 Hz |
50 Hz |
4. Photos of waffle biscuit stacker
5. Final product
About after sell service for our Aslan machinery co.,ltd
usually machine guarantee time is about 1 year . Within guarantee time. Machine breaking caused by machine itself
design defect , we are responsible for it .we can provided free charge breaking part, .If machine breaking caused by
humane factor , user need take responsibility for it , we will provided technical support .
About goods shipping of our Aslan machinery co.,ltd
We have long time working shipping forwarder. We can do our best to send machine to your port safe and sound .
If your need , we can help you do custom clearance .
About payment term for our Aslan machinery co.,ltd
Currently, in order to protect you and us rights .both us in safe , hope we can do business in safe way .
L/C(>20000USD),Western Union,T/T(bank transfer),Escrow
which one is you want , we can discuss it .
About our online Service:
24 hours online to solve any problem . Your email will be reply within 12 hours . Your satisfy is our pursuit .
sincerely hope our cooperation.
Contact information:
Contact :Larry He
Skype:Larry.he3
QQ:2746542104
Tel:86-18939526905
Fax:0086-371-53392380
Email:larry@aslanjixie.
com
Any questions if you have, please do not hesitate to tell us.
Your satisfaction is what we are always struggling for!
