Products description:
The water used in industry need to be processed by a number of stages, and processed by electricity dialysis, antidialysis and Na ion exchange are usually treated as main stages. In order to make sure these key stages are taken safely, efficiently, and economically, it is necessary to process the original water so as to meet the requirement for inputting water quality. In project we often purify, soften and adjust water quality before entering the main processing stages, known as water pretreatment or pretreatment, or pretreatment. The main targets of pretreatment are suspension, mechanical waste such as viscose debris particles, colloidad silica, microorganisms, active chlorine, and organic substance, which have an adverse impact on the follow-up treatment.
The result of pretreatment directly affects technical and economical effect and long-term safe operation of electricity dialysis, reverse osmosis,ion exchange and so on. It is an important stage in water
treatment.
Technical parameters:
| items | productivity(kg/h) | Standard rated power | dimension | pipe fittings, valve specs and materials |
| RF-BYROD -1000 | 1000 | 380V AC 50Hz 1.5kw | 2000*650*1650 | sus304 stainless steel, |
| RF-BYROD-2000 | 2000 | 380V AC 50Hz 2.2kw
|
2500*650*1750 | sus304 stainless steel, |
| RF-BYROD-3000 | 3000 | 380V AC 50Hz 3.0kw | 2600*650*1800 | sus304 stainless steel, |
|
RF-BYROD- 4000 |
4000 | 380V AC 50Hz 4.0kw | 3000*975*1750 | sus304 stainless steel, |
|
RF-BYROD- 000 |
5000 | 380V AC 50Hz 5.5kw | 3000*975*1750 | sus304 stainless steel, |
|
RF-BYROD- 6000 |
6000 | 380V AC 50Hz 5.5kw | 3000*975*1800 | sus304 stainless steel, |
|
RF-BYROD- 8000 |
8000 | 380V AC 50Hz 11kw | 3800*1200*1700 | sus304 stainless steel, |
|
RF-BYROD- 10000 |
10000 | 380V AC 50Hz 11kw | 3800*1200*1750 | sus304 stainless steel, |
|
RF-BYROD- 12000 |
12000 | 380V AC 50Hz 15kw | 3800*1200*1800 | sus304 stainless steel, |
|
RF-BYROD- 15000 |
15000 | 380V AC 50Hz 18kw | 3800*1270*1850 | sus304 stainless steel, |
Water treatment process flow chart
Company Profile:
Manufacturing Capacity:
Products Catergory:
1. Industrial water treatment equipment
2. Bean products equipment
3. Household water purified machine
