China High-efficiency Dry Powder Coating Mixer

China High-efficiency Dry Powder Coating Mixer photo-1
US$ 500 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Homogenizer
Product Type:
Fertilizer
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao ningbo shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Mixer Type Homogenizer
Product Type Fertilizer
Application Powder
Additional Capabilities Milling
Place of Origin Henan, China
Brand Name NMB
Model Number NMB2000 BS5027
Max. Loading Capacity 3500L
Voltage 220V,380V
Power(W) 1.5-18.5kw
Dimension(L*W*H) 600*1000*1200mm to 1350*2400*2680mm
Certification ISO,CE
Warranty 1 Year
After-sales Service Provided Overseas third-party support available

2014 hot sale dry powder coating mixer



dry powder coating mixer Mixing Equipment model NMB2000

China High-efficiency dry powder coating mixer

Descriptions of dry powder coating mixer

This equipment is developed based on the U-type horizontal spiral ribbon mixer which has been distributed to a lot of cities by us, after times of improvement. Since it is designed with three -layer successive spiral ribbons, it may have three layers of material flows; therefore, during the convention process, the materials maybe mixed rapidly and evenly in such a manner of penetrating through each other and accomplishing displacement.



high quality dry powder coating mixer Mixing Equipment color as clients request

China High-efficiency dry powder coating mixer

Characteristics of dry powder coating mixer

1. it maybe widely applied as it may mix the solid and solid (dry and dry)materials.

2.it has high degree of uniformity and may well mix the materials in a proportion of 1:1000, so such machine will be better when mixing materials with a great disparity in specific gravity.

3.it may be installed conveniently, discharge quickly, operate easily and occupy little area, and also it may have multi-functions by apply the design of lower opening according to the needs of users.

4.It may mix material gently and will not damage the initial state of the materials.

5.This equipment run stably and reliably and has fewer wearing parts, so it processes long service life and requires convenient maintenance and simple operation.



low price dry powder coating mixer Mixing Equipment raw material carbon steel/stainless steel

China High-efficiency dry powder coating mixer

Parameters of dry powder coating mixer

Model

Powder(kw)

Drum Size(mm)

Inner Volume(L)

Capacity(kg/batch)

Weight(kg)

NMB600

1.5

600*1000*1200

360

240

480

NMB800

2.2

680*1250*1360

450

300

620

NMB1000

3

750*1460*1500

800

400

860

NMB2000

5.5

800*1650*1740

1200

500

1700

NMB3000

7.5

1000*1880*1950

1800

1000

2600

NMB4000

11

1200*2050*2240

2200

1500

6200

NMB5000

18.5

1350*2400*2680

3500

2500

8600



dry powder coating mixer Mixing Equipment suitable objective dry powder

China High-efficiency dry powder coating mixer

Why choose perfect dry powder coating mixer

1. Our machine is big output, low residual amount, good sealing, no vibration, little dust, and short mixing time, etc.
 2. It can save labor and save cost, only 1 people can finish the production.

 3. It can realize loading-mixing-packing one-stop production.

 4. The occupied area is small, the height is less than 3 meters, easy to maintain.

 5. It is easy to operate, when operating; you should do as the instruction.

 6. Commonly used powder mixers are: coulter powder mixer, ribbon dry powder mixer, the powerful powder mixer, weightless powder mixer, and the double helix conical powder mixer, etc.

Pictures of dry powder coating mixer



high quality dry powder coating mixer Mixing Equipment main parts mixer & screw conveyor

China High-efficiency dry powder coating mixer

low price dry powder coating mixer Mixing Equipment Power 5.5kw

China High-efficiency dry powder coating mixer

dry powder coating mixer Mixing Equipment Drum size 800*1650*1740mm

China High-efficiency dry powder coating mixer

high quality dry powder coating mixer Mixing Equipment Inner Volume 1200L

China High-efficiency dry powder coating mixer

low price dry powder coating mixer Mixing Equipment Capacity 500kg/batch

China High-efficiency dry powder coating mixer

dry powder coating mixer Mixing Equipment Total Weight 1700kg

China High-efficiency dry powder coating mixer
