csm tube bending machine :
csm tube bending machine Bending Machines Processing type: pipe bender dies
Features of our machine:
NMB50NC high performance single-head hydraulic pipe bending machine, NC control, multi-groups program and multi-angles setting, makes your operation easy and convenient, widely used in blast pipe, furniture and other metal pipes processing.
csm tube bending machine Bending Machines opration type: NC
Technical parameter of our machine:
| Technical parameter | NMB38NC |
NMB50NC |
NMB63NC |
NMB75NC |
NMB80NC |
NMB100NC |
NMB114NC |
NMB133NC |
|
mm Biggest elbow picec ability |
φ38×2 |
φ50×2 |
φ63×2 |
φ75×2 |
φ80×2 |
φ100×3 |
φ114×6 |
φ133×6 |
|
mm Most greatly bevelling radius |
200 |
250 |
300 |
400 |
400 |
400 |
750 |
750 |
|
mm Smallest bevelling radius |
1.5D |
1.5D |
1.5D |
1.5D |
2D |
2D |
2D |
2D |
| Most greatly curving angle | 190° |
190° |
190° |
190° |
190° |
190° |
190° |
190° |
|
/sec Curving speed |
55° |
40° |
25° |
25° |
25° |
25° |
25° |
25° |
|
Mpa System most tremendous pressure |
15 |
15 |
15 |
15 |
15 |
15 |
15 |
15 |
|
L/min Oil pump displacement |
17 |
19 |
21 |
28 |
28 |
28 |
40 |
45 |
|
kw Electrical machinery power |
4 |
5.5 |
7.5 |
11 |
11 |
15 |
15 |
22 |
|
kg Mechanical and electrical weight |
800 |
1300 |
1600 |
2800 |
3000 |
3500 |
5000 |
6000 |
|
cm3 Mechanical and electrical volume |
260×65×125 |
295×80×125 |
315×80×125 |
395×96×125 |
380×82×130 |
426×96×130 |
450×150×150 |
500×160×150 |
Different shape of final products for your reference:
csm tube bending machine Bending Machines Application area: automobiles, furniture, exhaust pipe
csm tube bending machine Bending Machines colour: blue
csm tube bending machine Bending Machines
Our company other pipe benders pictures
csm tube bending machine Bending Machines
Things need to be noted:
1. We design and manufacture the tooling according to the tube's specification, so the customers should send us the following tube's specification details: Tube's material and Outside Diameter, Wall Thickness, Bending Radius. THIS IS VERY IMPORTANT!
2. The Min./Max. bending radius could be made to order according the customer's special requirement.
3. The length over mandrel could be made to order according the customer's special requirement.
About our service:
If you are interested with our products, please contact us freely. We have a perfect after-sales service system, and also a professional team. So please be assured to buy our products!
Machine matched with pipe bender machine:
csm tube bending machine Bending Machines
