Excellet Wheat Flour Grinding Machine, Wheat Flour Mills India, Mills to Grind Wheat

Excellet Wheat Flour Grinding Machine, Wheat Flour Mills India, Mills to Grind Wheat thumbnail-1
Excellet Wheat Flour Grinding Machine, Wheat Flour Mills India, Mills to Grind Wheat photo-1
US$ 1,700 - 3,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
NMB
Model Number:
NMB-400 BS2697
Contact Supplier Request Quote Chat Now
Henan Name Brand Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name NMB
Model Number NMB-400 BS2697
Production Capacity 1500kg/h-2000kg/h
Voltage 380v, 50hz, 3phase, 380v, 50hz, 3phase
Power(W) 11kw or 15hp
Weight 350kg, 350kg
Dimension(L*W*H) 1750*650*1200mm
Certification IOS
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Excellet wheat flour grinding machine, wheat flour mills

india, mills to grind wheat

wheat flour grinding machine Flour Mill Model NMB-400 wheat flour grinding machine

Excellet wheat flour grinding machine, wheat flour mills india, mills to grind wheat

Features of wheat flour grinding machine

1.This machine can grinding all kinds of crop stalks, such as corn stalks, peanut skins, peanuts shells, corn stems, clover, grass, peanut shoots, rice straw , soybeans vines, wheat straw etc.

2.This machine also can be used to pulverize corn, wheat, soy bean, cassava, sorghum, barley, grain, legumes, rice, beans, maize, dried sweet potato slices, soy bean cake etc.

3.Operation door can be moved fully -- easy to operate. It is driven by one motor, with no dead angle for grinding raw material. Widely used in grinding and processing, perfect for feed mill and fungus farm.

Advantages of wheat flour grinding machine

1.Adopts whole steel structure, Increase the machine service life.



2.Easy installation, operation and maintenance.


3.No need to fixed, Easy to move the machine and work convenient.


4.High efficiency, low energy consumption.


5.Available motor and diesel engine.


6.Small volume and low noise.


7.Quite popular in China and all around the world.

Specification of wheat flour grinding machine

Item

Specification

Model

NMB-400

Overall dimension:

1750*650*1200mm

Overall weight

350Kg

Rotor diameter

360mm

Matched power

11KW/380V

Diesel engine

15HP

Speed of main spindle

4600r/min

Hammer speed

86.7M/S

Size of input granules

202mm

Clearance between hammer & sieve surface

10mm

Hammer No.

12

Hammer arrangement

staggered parallel arrangement

Sieve disc width

200mm

Sieve disc cornerite

180o

Sieve pore specification

0.5mm – 5mm

Fan impeller diameter

260mm

Productivity for sieve pore diameter 2mm:

Corn: 1500-2000KG

Corn stalk: 400KG

Peanut shell: 500KG

Bean stalk: 800KG

Different grain and crops has different productivity

Other type machines (different output) are available.

Parameters of this series wheat flour grinding

machine



wheat flour mills india Flour Mill Corn capacity 1500kg/h-2000kg/h

Excellet wheat flour grinding machine, wheat flour mills india, mills to grind wheat



mills to grind wheat Flour Mill Cornstalk capacity 400kg/h

Excellet wheat flour grinding machine, wheat flour mills india, mills to grind wheat

Raw materials and final products show

wheat flour grinding machine Flour Mill Beanstalk capacity 500kg/h

Excellet wheat flour grinding machine, wheat flour mills india, mills to grind wheat

Workshop show

wheat flour mills india Flour Mill Peanut shell capacity 800kg/h

Excellet wheat flour grinding machine, wheat flour mills india, mills to grind wheat

mills to grind wheat Flour Mill Power 11kw or 15hp

Excellet wheat flour grinding machine, wheat flour mills india, mills to grind wheat

wheat flour grinding machine Flour Mill Voltage 380v, 50hz, 3phase

Excellet wheat flour grinding machine, wheat flour mills india, mills to grind wheat

Please contact us!!!

wheat flour mills india Flour Mill Weight 350kg

Excellet wheat flour grinding machine, wheat flour mills india, mills to grind wheat
