Applied ranges:
Suitable for cutting green and dry grass,corn stalk, cotton,rice,peanut,and wheat stalk.It can also be used to chop reed, wheat straw hood, bamboo, and branch ( Φ<50MM).
The processed mass can be used to feed cattle, goats, deer, and horses. It can also process cotton stalk, bark,
branches, they can also be used to generate electricity,make paper, artificial board and extract alcohol.
grass chopper machine Feed Processing Machines Model NMB-5.5
Usage of the final product:
1. It can be the feed of cow or sheep.
2. It can be used to electricity generating, paper making, artificial board making, ethanol extracting etc.
The machine can be matched with the dynamo, diesel engine or 30-50 hp tractor.
grass chopper machine price Feed Processing Machines Capacity 3-5ton per hour
Structure:
It mainly consist of feeding structure, chopping structure, throwing structure, driving structure, running gear,
protective device and rack etc.
grass chopper machine for animals feed Feed Processing Machines No. of blades 4
Features
1. Compact mechanism, small volume, light weight, easy to move
2. The body is made of full steel plate material quality, durable in use.
3. The roller can automatically "eat material", reducing the the intensity of labor while emptying, also improving the efficiency.
4. The four blades all adopt 65 manganese steel knife with sharp blade. The grass cutted out is parallel and level with high broken section rate and good quality.
5. The machine is equipped with overload protection device so as to avoid the jamming fault caused by feeding too much one time.
Technology data
MODEL |
No. of blades |
Output(T/H) |
motor (KW) |
Diesel Engine (HP) |
Dimension (mm) |
NMB-3 |
4 |
1-1.5 |
3 |
≥4 |
820*460*1160 |
NMB -4 |
4 |
2-2.5 |
4 |
≥8 |
1230*1150*1695 |
NMB -5.5 |
4 |
3-4 |
5.5 |
≥12 |
1737*1575*2315 |
NMB -7.5 |
4 |
5-6.5 |
7.5 |
≥15 |
2147*1600*2756 |
NMB -15 |
3 |
9-10 |
15 |
≥28 |
2620*2140*4110 |
NMB -18.5 |
3 |
11-12 |
18.5 |
≥30 |
2630*2230*4120 |
grass chopper machine Feed Processing Machines Power 5.5kw
grass chopper machine price Feed Processing Machines Diesel Engine 12HP
international standard export wood fumicated box package
grass chopper machine for animals feed Feed Processing Machines Material made of full steel plate
