Home > Manufacturing & Processing Machinery > Woodworking Machinery > Other Woodworking Machinery > Turkey Project Tea Waste Briquette Screw Machine

Turkey Project Tea Waste Briquette Screw Machine

Turkey Project Tea Waste Briquette Screw Machine photo-1
US$ 2,400 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
NMB
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name NMB
Model Number ZBJ-Series BS6941
After-sales Service Provided Engineers available to service machinery overseas

tea waste briquette screw machine

tea waste briquette screw machine Other Woodworking Machinery Model ZBJ-Series briquette machine

Turkey project tea waste briquette screw machine

Product Description

How to produce Charcoal from briquette?

Our tea waste briquette screw machine is mainly used to produce briquettes with high density from all kinds of biomass like wood, sawdust, rice husks and others. The final briquettes are used as fuel for heating and cooking, and are widely used in many industries like boiler industry. The process for producing charcoal briquette is the followoing:

1. Crusher---crush the raw material into powder size



tea waste briquette screw machine Turkey project Other Woodworking Machinery Capacity 150-450kg/h

Turkey project tea waste briquette screw machine

2. Dryery---dry the material by machine or dried it in the sun , till the moisture is less than 12%;



tea waste briquette screw machine Other Woodworking Machinery Raw materail for briquette machine wood,rice husk,straw,stalk,sawdust,branch and so on

Turkey project tea waste briquette screw machine

3. Briquetting---put the material into feed inlet of tea waste briquette screw machine, there is no need to add any binder;



tea waste briquette screw machine Other Woodworking Machinery Material size less than 5mm

Turkey project tea waste briquette screw machine



tea waste briquette screw machine Turkey project Other Woodworking Machinery Material moisture should be around 12%

Turkey project tea waste briquette screw machine

4. Carbonization---if you want to get charcoal briquettes in the end, use a carbonization stove to carbonize them.



tea waste briquette screw machine Other Woodworking Machinery Power 11-22kw

Turkey project tea waste briquette screw machine

5,Charcoal--- high quality no smoking charcoal when burning



tea waste briquette screw machine Other Woodworking Machinery Final briquettes diameter 50/60/70/80/90mm

Turkey project tea waste briquette screw machine

tea waste briquette screw machine specification

Model

ZBJ-I

ZBI-II

ZBJ-III

ZBJ-NEW

Capacity(kg/h)

150-200

200-300

350-400

400-450

Power(kw)

11

15

18.5

22

Dimension(mm)

1160*745*1250

1700*800*1280

1920*630*1550

195*650*1650

Electric Heater(kw)

3*1.5

3*1.5

3*2.2

3*2.2

Diameter(mm)

50

50/60/70

50/60/70/80

50/60/70/80/90

Weight(kg)

550

650

750

800

what raw material can use used for our tea waste briquette screw machine ?

Many kinds of agro-wastes can be used to make briquettes, such as groundnut-shell, sugarcane residue, caster shells, stalk, sawdust, coffee husk, paddy straw, sunflower stalk, cotton stalks, tobacco waste, mustard stalk, Jute wastes,  bamboo dust, tea waste, wheat straw, palm husk, soybeans husk, rice husks, forestry wastes, wood chips and many other Agro wastes.

tea waste briquette screw machine Turkey project Other Woodworking Machinery Package wood box

Turkey project tea waste briquette screw machine

Briquette machine molds and final products show

tea waste briquette screw machine Other Woodworking Machinery Warranty one year after sales

Turkey project tea waste briquette screw machine

payment terms

T/T, L/C, or Western Union

Several machines working together picture show

tea waste briquette screw machine Other Woodworking Machinery Factory professional production line

Turkey project tea waste briquette screw machine

tea waste briquette screw machine Turkey project Other Woodworking Machinery

Turkey project tea waste briquette screw machine

Our company other kinds fuel machine for you to choose

1. Coal/charcoal stick making machine: raw materials should be coal/charcoal powder, or carbonized biomass like wood, sawdust, rice husks, coconut shells and others. Final products can be round, hexagonal, square and other shape sticks.

2. Coal/charcoal balls making machine: raw materials should be coal/charcoal powder, or carbonized biomass like wood, sawdust, rice husks, coconut shells and others. Final products can be round, oval, and pillow shape balls.

tea waste briquette screw machine Other Woodworking Machinery

Turkey project tea waste briquette screw machine

Company Information



tea waste briquette screw machine Other Woodworking Machinery

Turkey project tea waste briquette screw machine

CE certificate for your reference

tea waste briquette screw machine Turkey project Other Woodworking Machinery

Turkey project tea waste briquette screw machine

Welcome to contact for further details

tea waste briquette screw machine Other Woodworking Machinery
