New !! Industrial Fish Dryers(for Fishmeal Production)

New !! Industrial Fish Dryers(for Fishmeal Production) photo-1
US$ 8,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
NMB
Model Number:
LH BS8028
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Henan, China
Brand Name NMB
Model Number LH BS8028

industrial fish dryers

Machine structure

The main machine dryer, consists of a horizontal cylinder and a steam heated rotor which is equipped with heating plates. There are propellers in the plates, the angel of which could be adjusted, to push the meal ahead. The steam through the rotor is distributed through the heating plates evenly. The steam and the condensed water flow separately in the coiled tubes in the heating plates.
The discs and propellers supply good agitation of fish meal, a large area of contact between meal and disc and, accordingly, means for efficient dehydration.

Performance and Characteristics

1,Transfer steam to the outer jacket,main shaft coil or steam box and heat ,to increase the heating area,make the heat efficiency reach up to 95% and ensure the intensive drying of material

2,the steam dome and pipelines adopt stainless steel,to improve corrosion resistance and extend service life

3,According to the material properties,increase block knives,to solve the sticking problems of sticky material and thus extend the application scope of the equipments

Scope of Application

The machine applies to the drying of the high humidity and high viscosity material,such as feather meal,fish meal,blood meal,meat meal,kitchen waste,Etc


Technology data

model

Tank size

0.6 MPS

gas consumption

Evaporation

Heat-

Exchange

 area

Motor power

Reducer

Inner mm

Lenght mm

Kg/h

Kg/h

M2

kw

LH1200

1200

6000

400

250-300

55

18.5-4

Zly224

LH1300I

1300

6000

450

300-350

64

22-4

ZLY250

LH1300II

1300

7000

550

350-400

71

22-4

ZLY250

LH1300III

1300

8000

600

400-450

78

30-4

ZLY280

LH1400

1400

7000

650

450-500

81

30-4

ZLY280

Machine Pictures



industrial fish dryers Feed Processing Machines Function used for dry feather meal,fish meal,blood meal,meat meal,Kitchen

New !! industrial fish dryers(for fishmeal production)

This bellow is 1Ton per day picture we export to Indoneisa in one 20GP



steam tube rotary dryer Feed Processing Machines

New !! industrial fish dryers(for fishmeal production)

industrial steam dryer Feed Processing Machines

New !! industrial fish dryers(for fishmeal production)

industrial fish dryers Feed Processing Machines

New !! industrial fish dryers(for fishmeal production)

steam tube rotary dryer Feed Processing Machines

New !! industrial fish dryers(for fishmeal production)
