Product Details
Condition: | New | Type: | Cutter Suction Dredger | Power Type: | Diesel |
Dredging Depth: | 15 m | Draught: | 120 cm | Place of Origin: | Shandong, China |
Brand Name: | Heng An | Model Number: | HACSD200 | Dimension(L*W*H): | 12.5*4.6*1.3m |
Weight: | 80t, 80T | Certification: | ISO9001 | Warranty: | 12months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Hydraulic River Dredge machine
1).Completely assembled and fully tested afloat before delivery
2).Simple ,rapid assembly and dismantling
3).Standard design, allowing early delivery and low price
4).Spare parts available from stock
5).Reliable hydraulic system
6).Fresh water engine cooling system
7).One man operation
8).Efficient fuel consumption
The dredger is equipped with a rapid connection-disconnection system for the pontoons, achieved using bolts at deck level, and hooks at the bottom. Further salient features of the vessel are the compact dredge pump drive incorporating a reduction gear with integrated pump bearing and a fresh water engine cooling system, based on the well cooling principle.
1.--Parameter
Can modify and adjust according to customers' project requirement.
No. | Principal Particulars | |||||||
1 | Model | HACSD200 | HACSD260 | HACSD300 | HACSD350 | HACSD400 | HACSD450 | HACSD500 |
2 | Max. Production Capacity(solid sand) | 100m3/h | 150m3/h | 220m3/h | 300m3/h | 400m3/h | 500m3/h | 640m3/h |
3 | Max. Discharge Distance | 900m | 1000m | 1000m | 1200m | 1300m | 1400m | 1700m |
4 | Dredge Pump Suction/discharge pipe dia.(mm) | 250/200 | 300/250 | 350/300 | 400/350 | 450/400 | 400/450 | 550/500 |
5 | Main Engine power(KW) | 176 | 294 | 330 | 470 | 735 | 735 | 882 |
6 | Cutter Power(KW) | 25 | 30 | 50 | 70 | 75 | 110 | 140 |
7 | Hydraulic Ladder winch | 30KN 100m | 40KN 100m | 40KN 100m | 60KN 110m | 80KN 110m | 100KN 120m | 100KN 120m |
8 | Hydraulic Swing winch(2sets) | 30KN 100m | 40KN 100m | 40KN 100m | 60KN 100m | 80KN 110m | 100KN 110m | 100KN 110m |
9 | Spuds | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
10 | Control system | PLC | PLC | PLC | PLC | PLC | PLC | PLC |
.
2.--Customers visit our Factory
We will show you detailes and much more things about our Group company.Many senior Engineers and professional technicians composed of the Class One Technical Department.
3.--Consult and meeting with engineers
4.--Prodution
After order,we prepare all of the materials to produce .
5.--Test before shiping and transportation to the seaport
We will test the dredger well before shipment and transport it to the seaport by truck or containers.
Our dredgers working in the work site in different places of the world ,such as Bangladesh,Southeast Asia,Africa,South America and so on.
6.--Dredger spare parts
We also supply the whole set of spare parts for dredgers.
7.Certificate:By BV
8.--Contacts :more details please don't hesitate to contact me.
All ofthe spare parts of the dredger can be available within one week!
Wish you a nice day!
