Wheel Loader 3t

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

SAM

Model Number:

836

Weifang Heng An Imp& Exp Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QIngdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name SAM

Model Number 836

Place of Origin Shandong, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 6890*2430*3070mm

Rated Load 3000kg

Certification ISO

Warranty 12months

After-sales Service Provided Overseas service center available

wheel loader 3t

Performance	1	rated loading	3000kg
	2	overall weight	9600kg
	3	rated bucket capacity	1.7-2.5m³
	4	maximum tractive force	97KN
	5	maximum breakout force	127KN
	6	maximum grade ability	30°C
	7	maximum dump height	3100mm
	8	maximum dump reach	1006mm
	9	overall dimension (L×W×H)	6890×2430×3070mm
	10	minimum turning radius	5097mm
Engine	11	model	YC6B125-T20
	12	type	lnline water cooled, four stroke
	13	No. of cylinder-bore/stroke	6—108×125mm
	14	rated power	92kw(125HP)
	15	maximum torque	500N.m
	16	min fuel-consume ratio	≤210g/kw.h
Transmission system	17	torque converter	YJ315—x
	18	gearbox mode	Power shift normally engaged straight gear
	19	gear shift	4forward shift 2 reverse shift
	20	maximum speed	40km/h
Drive axles	21	main reducing mode	Bevel gear grade lreduction
	22	decelerating mode	Bevel gear grade lreduction
	23	wheel base (mm)	2660mm
	24	wheel tread	1800mm
	25	ground clearance	400mm
Hydraulic system	26	system working pressure	16.5MPa
	27	boom lifting time	4.83s
	28	total time	9.15s±0.5s
	29	fuel tank capacity	156L
	30	function of leveling automatically	yes
Brake system	31	service brake	air assist disc brake on 4 wheels
Brake system	32	parking brake	Manual disk brake
Tyre	33	type specification	17.5-25
	34	front tyre pressure	0.4Mpa
	35	rear tyre pressure	0.35Mpa
