150hp 1504 Tractor for Big Farm

150hp 1504 Tractor for Big Farm thumbnail-1
150hp 1504 Tractor for Big Farm photo-1
US$ 35,000 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Weifang Heng An Imp& Exp Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Certificate CE
Brand Name HENG AN
Model Number 1504
Place of Origin Shandong, China
After-sales Service Provided Overseas service center available

150hp farm tractor

150hp 1504 tractor for big farm150hp 1504 tractor for big farm150hp 1504 tractor for big farm

 Standard Configuration and Technical Data

Shangchai six cylinder engine is designed with fully enclosed cab, air heater,air conditioner,14+7 shifts of transmission, shifting synchronizer, integrated frame, driving system with modularized structure,imported front axle,rear axle for engineering machinery, after the double configuration, caliper disc brake, revolution for power output shaft of dual revolution 540/1000r/min, fully hydraulic front wheel steering, three groups of single/dual action hydraulic output, plough depth control method by position,floating control, and suspension mechanism of rear-mounted Category III,and fourteen pieces of front counterweight of 504kg

Items

Unit

1504

Net Power of Engine

kW(HP)

118(160)

Driving Method



4x4(Four-wheel drive)

Dimension, Length/Width (tread) /Height (Cab Top)

mm

5830/2420(3510)/3010

Wheelbase

mm

3080

Wheelbase of Front Wheel

mm

1928-2240

Wheelbase of Rear Wheel

mm

1952-2568

Minimum Ground Clearances

mm

415

Minimum Steering Circle Radius

mm

6900

Minimum Working Weight

kg

7300

Front Counterweight≤

kg

504

Rated Traction Force

kN

36

Power Output Shaft

Model



Independent Rear-mounted

Standard RPM

r/min

Double speed 540/100

Maximum Lifting Force

kN

36

forward gear

Low RPM

The number of stalls



7

Driving Speed

km/h

2-17

High RPM

The number of stalls



7

Driving Speed

km/h

3-30

Reverse Shift

The number of stalls



7

Driving Speed

km/h

2-17

Specification of Tire

Front Wheel



14.9-28R1

Rear Wheel



18.4-38R1

Diesel Engine

Nominated Power/RPM

kW/r/min

118/2000

Nominated Working Condition Fuel
Oil Consumption Rate

g/kW·h

≤230



150hp 1504 tractor for big farm
