al-pet tape/pp foamed tape/pp filler cable material
1. 100% PP filler yarn
Linear Density |
12000D |
18000D |
22000D |
28000D |
33000D |
48000D |
60000D |
70000D |
90000D |
|
(weight)g/m |
1.33+0.13 -0.13 |
2+0.2 -0.2 |
2.44+0.22 -0.22 |
3.11+0.31 -0.31 |
3.67+0.37 - 0.37 |
5.33+0.53 -0.53 |
6.67+0.67 -0.67 |
7.77+0.77 -0.77 |
10+1.0 -1.0 |
|
Diameter (mm) |
1.5 |
2 |
2.3 |
2.5 |
2.7 |
3.2 |
3.8 |
4.5 |
5 |
|
Breaking Strength (kg) equal or more |
24 |
36 |
44 |
56 |
66 |
96 |
120 |
140 |
180 |
|
(%) Breaking Elongation equal or more |
10 |
10 |
10 |
10 |
10 |
10 |
10 |
10 |
10 |
|
Hot Shrinkage rate (%) |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
2.cheap cable pp filler yarn with mixed caco3 :
1-----5 PLY,2-----50MM,4-----8 TPM
this kinds of pp cable filler yarn price is the cheapest
| Advantage: Cheap price, suitable for large cable. |
|
Item |
|
|
|
|
Linear Density |
D |
+/-10% |
2------50mm Denier:20000D---800KD |
|
Breaking Strength |
g/D |
0.2---0.6 |
|
|
Breaking Elongation
|
% |
20 |
|
|
Hot Shrinkage rate
|
% |
6 |
100°C*1min. |
|
Tube size |
mm |
1 ID: 90, H:255 2. ID:38,H:220 3. ID:50,H:270 4. ID:75, H:440 |
|
|
Packing |
6----50KG/ROLL |
||
3. pp twist wire cable pp filler yarn,20---80TPM,1----8MM
4.FR wire cable pp filler , LOI >29
Our advantage:
A. The best price at good quality
B. Excellent service and prompt delivery
C. Effective and attractive packaging
wire cable pp filler yarn
| 100% pp , pp filler Specificatioms | ||||||
| Item | Unit | standard | Remark | |||
| Fineness | D | specification±8% | 3000D-300000D | |||
| Breaking | g/d | >2 | ||||
| tenacity | ||||||
| Tensibility | % | <20 | ||||
| shrinkage | % | <6 | 120*30min | |||
| in hot air | ||||||
| Appearance | Natural Color or White,color | |||||
| obvious stations | ||||||
In a wide range of denier from 3000D to 300KD,Widely used in wire and cable.These are sold in shrink-wrapped coreless rolls,rolled on paper cores and capable of working with continuing throughout their length.
| pp+caco3 wire cable pp filler Specificatioms | ||||||
| Item | Unit | standard | Remark | |||
| pp filler Fineness | D | specification±8% | 3000D-300000D | |||
| pp filler Breaking | g/d | >0.3,>1g/d | ||||
| tenacity | ||||||
| Tensibility | % | <20 | ||||
| shrinkage | % | <10 | 120*30min | |||
| in hot air | ||||||
| Appearance | Natural Color or White,No | |||||
| obvious stations | ||||||
5.high tenacity polyester yarn and polyester thread
| polyester sewing thread Spec. |
sewing thread weight (g/spool) |
sewing thread Length (Y/spool) |
|
840D/3 (0#) |
90 | 300----5000 |
|
630D/3 (5#) |
90 | 380----80000 |
|
500D/3 (10#) |
90 | 550---9000 |
|
250D/4 (20#) |
90 | 800-----12000 |
|
250D/3 (30#) |
90 | 1100---20000 |
|
250D/2 (40#) |
90 | 1600----25000 |
|
150D/3 (60#) |
90 | 1600------30000 |
|
120D/3 (80#) |
90 | 2100-----300000 |
6. aramid yarn:200D,400D,1000D,1500D,3000D
kelvar aramid yarn
aramid yarn is ahigh performance material,it comnines the characteristics of high strength and light weight. under the condition of equal weight,it is 5 times the strength of steel wire,2.5 times fiberglass.
ARAMID YARN PROPERTY
| aramid yarn Denier (D) |
aramid yarn Break Strength (kg) |
Klongation At Break (%) |
aramid yarn Modulus (g/D) |
1000 |
20 |
3.5 |
24.0 |
1500 |
32 |
3.8 |
24.0 |
400 |
9.5 |
3.3 |
24.0 |
20S/2 |
3 |
3.0 |
15.0 |
7. al-pet ,pp foamed tape
...
