Help CenterPower Cable Flame Retardant TPE Resin of UL & CSA
Related Products
-
Halogen Free Flame Retardant Wire TPE for Apple CableUS$ 7 - 7MOQ: 200 Kilograms -
Halogen Free Flame Retardant Anti-UV DC Power Cable TPEUS$ 6.5 - 6.5MOQ: 200 Kilograms
-
UL Standard PVC Compound for Wire CableUS$ 1 - 1.1MOQ: 3000 Kilograms
-
China Cable Pvc Compound for Wire CableUS$ 0.9 - 1.1MOQ: 3000 Kilograms
-
China Eco-friendly Origin Plastic Pvc Resin for CableUS$ 1 - 1.1MOQ: 3000 Kilograms
It's HFFR thermoplastic TPE elastomer cable compound
Appliance: mouse wire,headphone cable,USB wire,HDMI wire,communication line,power line,SATA line,computer cable and related injection moulding etc.
Characteristics:
- Excellent touch feeling and flexibility
- Excellent flame retardant performance, passing VW-1 test
- Excellent physical and chemical properties as well as mechanical and electrical performance
- Excellent surface appearance and mutli-choice such as frosting, glossy, mist, half mist and shining surfaces
- Environmental friendly, non-halogenated flame retardant, PH3 free
Application:
Widely applied in the UL standard power cable insulation, jacket as well as USB, HDMI, SATA and ribbon line
Specifications:
| NO | ITEMS | UNIT | EX7535X | EX8035X | EX8535X | EX9125X | EX9735X | |
| 1 | Density | g/cm3 | 1.08 | 1.07 | 1.09 | 1.08 | 1.09 | |
| 2 | Hardness | Shore A | 75 | 80 | 85 | 91 | 97 | |
| 3 | Tensile Strength | MPa | 9.6 | 10.4 | 11.4 | 10.4 | 15.6 | |
| 4 | Elongation at Break | % | 400 | 400 | 350 | 400 | 250 | |
| 5 | Aging | condition | ℃×h | 136×168 | 136×168 | 136×168 | 121×168 | 136×168 |
| Tensile Strength retention | % | 110 | 118 | 104 | 108 | 87 | ||
| Elongation retention | % | 87 | 96 | 93 | 86 | 80 | ||
| 6 | Flame Retardant Performance | / | VW-1 | VW-1 | VW-1 | VW-1 | VW-1 | |
| 7 | Melt Flow Rate | g/ 10min |
4 210℃/10kg |
3/ 210℃/10kg |
3 210℃/10kg |
5 190℃/10kg |
9 210℃/10kg |
|
| Typical application | Jacket and insulation | Jacket and insulation | Jacket and insulation | Jacket and insulation | Jacket and insulation | |||
Noted:
Typical values only for material selection. Not to be used for part or tool design. Variation within normal tolerances is possible for various colors.
Type |
Density/g/cm3 |
Elongation/% |
Tensile Strength/MPa |
Hardness/ShoreA/D |
Flaming Rating |
X-75A3110 |
0.99 |
600 |
11.0 |
76A |
-- |
X-80A3110 |
0.98 |
600 |
14.0 |
80A |
-- |
X-85A3111 |
1.08 |
250 |
11.0 |
85A |
HB |
X-90A3111 |
1.10 |
350 |
13.0 |
89A |
HB |
X-85A1112 |
1.07 |
250 |
11.0 |
85A |
V0 |
X-90A1112 |
1.08 |
200 |
12.0 |
90A |
V0 |
X-90A2112 |
1.08 |
300 |
14.0 |
90A |
V0 |
X-40D2112 |
1.07 |
200 |
14.5 |
42D |
V0 |
X-85A3112 |
1.10 |
300 |
9.5 |
86A |
V0 |
X-90A3112 |
1.12 |
250 |
12.0 |
90A |
V0 |
X-85A3102 |
1.06 |
350 |
8.0 |
85A |
|
X-50D3102 |
1.06 |
250 |
11.0 |
50D |
V0 |
The technical parameters are typical values, it can customize according to customer's requirements.
We could support packaging agreed on by both manufacturer and client !
